The product name
TE244
Print pattern
Heat sensitive/heat transfer
The resolution of the
203 DPI
Print speed
152 mm
Maximum print width
104 mm
Maximum print length
2794 meters
Central processing unit (CPU)
32-bit efficient processors
memory
• 8 MB Flash menmory
• 16 MB SDRAM
The power supply
• the external voltage switch automatically switches the power supply
• ac input: ac100-240v, 2.5a, 50-60hz
• dc output: DC24V, 2.5 A, 60W
The shell
Double layer ABS plastics
Operation panel
Power switch, paper key, LED indicator (3 colors: green, orange, red)
size
204 mm (wide) x 164 mm (high) x 208 mm (long)
Carbon belt
300 meters, the maximum 67-mm outer diameter, 1 "carbon tape scrollbars (outer coiled carbon strip)
The maximum size of internal paper roll
127 (5 ") diameter
Bar code
A one-dimensional bar Code 128 ucc, Code128subsetsA, B, C, EAN128, lnterleaved 2 of 5, 2 of5with lnterleaved check digit, Code 39, Code39with check digit, Code 93, EAN13, EAN8, UPCA, UPEC, EAN and UPC2 (5) who add - om, Codabar, Postnet, MSI, MSI with the check digit, PLESSEY, China post, ITF14, Code11, TELEPEN, TELEPENN, PLANET, cODE49, Deutsche post ldentcode, Deutsche post Leitcode, LOGMARS
2d barcode GS1DataBar, GS1 DataMatrix, Maxicode, PDF417, QR Code, Micro PDF417
