The performance parameters
Image sensor
CMOS
pixel
752 * 480 CMOS
Read code system
2D PDF417, QR Code, Data Matrix, Chinese Sensible Code, etc.
1D EAN -13, EAN -8, Code 39, upc-a, upc-e, ISBN, Codabar, Code 128, Code 93,
Itf-6, itf-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5,
Matrix 2 of 5, GS1 Databar, Code 39, Code 11, msi-plessey, Plessey, etc.
Read the precision
P 5 mil
Exercise tolerance
2.5 m/s
Barcode sensitivity
Tilt + 60 ° @ 0 ° Roll and 0 ° Skew
+ 360 ° rotating @ 0 ° Pitch and 0 ° Skew
Plus or minus 55 ° deflection @ 0 ° Roll and 0 ° Pitch
Minimum contrast
25% or higher
Data interface
RS - 232, USB
Physical parameters
Size (length x width x height)
83 * 81 * 81 mm
The weight of the
292 g
prompt
Buzzer, LED indicator light
current
The working current is 150mA
Standby current 120mA
Environmental parameters
Working temperature
- 20 ℃ ~ 50 ℃
Storage temperature
- 40 ℃ ~ 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 14 kV (air discharge), plus or minus 8 kV (direct discharge)
Drop height
Six surfaces with no less than 1.2 meters (each of the six surfaces)
Protection grade
IP52
certification
FCC Part15 ClassB, CE EMC Class B
Accessories list
USB USB cable to connect to the receiving host.
RS232 RS232 data line for connection information receiving host with adapter interface.
Power adapter 5V power adapter with data line to power the scanner.
Output: DC 5V, 1.5a input: AC 100 ~ 240V, 50 ~ 60Hz
* specifications are subject to change without prior notice
