Wired
wireless
Scanning performance
image sensor
CMOS
pixel
752 * 480
lighting
Red LED (622nm~628nm)
Symbologies
2D, PDF417, QR, Code, Data, Matrix, Chinese, Sensible, Code (Han Xinma), etc.
1D EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2, of 5, Industrial 2, of 5, Standard 2, of 5, Matrix 2, of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc.
Reading accuracy *
More than 3mil
Typical reading depth of field *
EAN- 13, 40mm-370mm (13mil)
Code 39, 35mm-185mm (5MIL)
Code128 60mm-125mm (3mil)
DM 40m-120mm (10mil)
QR 20mm-175mm (15mil)
PDF 45mm-120mm (6.7mil)
Movement tolerances (optional)
Up to 50cm/s
Bar code sensitivity * *
Tilt + 55 degrees; rotate 360 degrees; deflection + 60 degrees
Fov
Horizontal 43.9 degrees, vertical 33.2 degrees
Symbol contrast *
More than 25%
Machinery /
Electrical parameter
communication interface
USB, RS232, PS2
USB, RS232
Appearance size (mm)
The size of the scanning gun is 113.5 (W) * 73 (D) * 159 (H)
Base size 195 (W) * 82.5 (D) * 47 (H)
weight
Scan gun weight 148 G
The scanning gun weighs 252 g (including batteries)
Seat weight 150g
Prompt mode
Buzzer, LED indication
working voltage
DC 5V + 0.25V
Working current
240mA
290 + 30mA
Standby current
20mA
50mA
Environment parameter
working temperature
-20 DEG C, ~60 DEG C
Storage temperature
-40 DEG C, ~70 DEG C
relative humidity
5%~95% (without condensation)
Electrostatic protection
+ 8 KV (contact discharge); + 15 KV (air discharge)
drop height
1.5 meters
Protection level (optional)
IP42
Optional
Wireless performance
Communication mode
Synchronous mode
Synchronous mode / asynchronous mode / batch mode
Wireless standard
/
2.4 to 2.4835 GHz (ISM Band) band using Zigbee wireless communication technology
Transmission distance (open area)
/
50 meters
storage capacity
/
128K
Battery capacity
/
2200 mAh
Battery charge time
/
3.5 hours
Continuous working time
/
More than 12 hours or 40000 times of continuous scanning
International certification
FCC, Part15, Class, B, CE, EMC, Class, B
Parts list
Data line
USB
B.
B.
RS-232
B.
B.
PS/2
B.
*
Fixed support
B.
*
Intelligent support
B.
*
The power adapter
5V power adapter, its output is: DC, 5V, 0.5A; input is: AC, 100~240V, 50~60Hz
* test conditions: ambient temperature =23 degrees; ambient illumination =300 LUX
* * test conditions: test distance = (minimum depth of field + maximum depth of field) /2; ambient temperature =23 DEG C; ambient illumination =300 Lux
2D:QR CODE; 10 Bytes; minimum bar width =15 mil; PCS=0.8;
* specifications subject to change without notice *
