The performance parameters
The light source
Red LED (610nm ~ 640nm)
Read code system
EAN - 13, EAN - 8, upc-a, upc-e, ISSN, ISBN, Codabar, Code 128, Code 93, itf-6, itf-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5,
Matrix 2 of 5, GS1 Databar, Code 39, Code 11, msi-plessey, Plessey.
Read the precision
P 5 mil
Typical reading depth
EAN 13 52 mm - 595 mm (13 mil)
Code 39, 55 mm - 130 mm (5 mil)
Barcode sensitivity
Tilt + 60 ° @ 0 ° Roll and 0 ° Skew
Rotation plus or minus 30 ° @ 0 ° Pitch and 0 ° Skew
Deflection + 60 ° @ 0 ° Roll and 0 ° Pitch
Minimum contrast
The reflection difference is greater than 30%
Scanning speed
300 times/SEC.
Data interface
The RS - 232, USB, PS / 2
Physical parameters
Size (length x width x height)
145 * 101 * 101 mm
The weight of the
190 g (including USB cable)
prompt
Buzzer, LED indicator light
Power adapter (optional)
Output: DC 5V, 1.5a input: AC 100 ~ 240V, 50 ~ 60Hz
current
Maximum current < 130mA
The working current is 115mA plus or minus 10mA
Standby current 14mA
Environmental parameters
Working temperature
- 20 ℃ ~ 60 ℃
Storage temperature
- 40 ℃ ~ 80 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
KV (contact discharge); + 10 KV (air discharge)
Drop height
1.2 meters
Protection grade
IP42
certification
FCC Part15 Class B, CE EMC Class B
* specifications are subject to change without prior notice
