The performance parameters
Image sensor
640 x 480 CMOS
Read code system
2D PDF417, QR Code (qr1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140),
1D Code 128, UCC/EAN - 128, AIM - 128, EAN - 8, EAN - 13, ISBN/ISSN, upc-e, upc-a, Interleaved 2 of 5, itf-6, itf-4, Matrix 2 of 5, Industrial 25,
Standard 25, Code 39, Codabar, Code 93, Code 11, Plessey, msi-plessey, GS1 - DataBarTM (RSS), (RSS - 14, RSS - Limited, RSS - Expand)
Read the precision
P 3 mil
Typical reading depth
EAN 13 40 mm - 355 mm (13 mil)
Code 39 28 mm - 155 mm (5 mil)
PDF 417 28 mm - 95 mm (6.67 mil)
The Data Matrix 25 mm - 95 mm (10 mil)
QR 25 mm - 150 - mm (15 mil)
Barcode sensitivity
Tilt + 60 ° @ 0 ° Roll and 0 ° Skew
Rotate 360 ° @ 0 ° Pitch and 0 ° Skew
Plus or minus 55 ° deflection @ 0 ° Roll and 0 ° Pitch
Minimum contrast
30%
Data interface
RS - 232, USB
Physical parameters
Size (length x width x height)
145 * 101 * 101 mm
The weight of the
165 g
prompt
Buzzer, LED indicator light
Power adapter (optional)
Output: DC 5V, 1.5a input: AC 100 ~ 240V, 50 ~ 60Hz
current
Maximum current < 300mA
Work current 140mA plus or minus 15mA
Standby current 14mA plus or minus 2mA
Environmental parameters
Working temperature
- 20 ℃ ~ 50 ℃
Storage temperature
- 40 ℃ ~ 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
KV (contact discharge); Plus or minus 15 KV (air discharge)
Drop height
1.2 meters
Protection grade
IP42
certification
FCC Part15 Class B, CE EMC Class B
* specifications are subject to change without prior notice
