Scanning performance
Image sensor
The CCD
pixel
2500
lighting
Red LED (620nm ~ 630nm)
af
Red LED (620nm ~ 630nm)
Maximum decoding velocity
300 times/SEC.
Read code system
1D AIM 128, Code 11, Code32, Code 39, Code 93, Code 128, Codabar, COOP 25, COOP 25, Deutsche 12, Deutsche 14, EAN - 8, ian-13, and aban, GS1-128, GS1-128, ISBN, ISSN, itf-6, itf-14, msi-plessey, Plessey, Plessey, upc-a, upc-e, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, Matrix 2 of 5, Standard 2 of 5
Accuracy of literacy
3 mil
Barcode sensitivity * *
tilt
Plus or minus 60 °
Deflection (skew)
+ 70 °
A typical reading of depth of field *
Code 39 (5mil) 80mm ~ 180mm
EAN -13 (13mil) 40mm ~ 480mm
The view point of
53 ° plus or minus 2 °
Symbol contrast
20% or higher
Mechanical /
Electrical parameters
Communication interface
RS232, USB, PS / 2 (optional)
prompt
Buzzer, LED indicator
Appearance size (mm)
145 (W) x 101 (D) x 68 (H)
Working voltage
5 VDC plus or minus 5%
The weight of the
120 g
The rated power
345mW (typical value)
Current @ 5 VDC
Working current
70.4 mA (typical value), 96.8 mA (maximum)
Standby current
57.6 mA
Environmental parameters
Working temperature
- 20 ℃ ~ + 60 ℃
Storage temperature
- 40 ℃ ~ + 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 16kV (air discharge), plus or minus 8 kV (direct discharge)
Drop height
1.5 meters
Protection grade
IP42
International certification
FCC Part15 Class B, CE EMC Class B
Accessories list
cable
USB
The RS - 232.
PS / 2
USB cable to connect to the machine and to receive the host.
The RS232 data line is used to connect the machine and the information receiving host.
PS / 2 data line used to connect the machine and the information receiving host.
stents
Smart stent
The device is used to support the intelligent switching scanning mode.
Data editing function
Support, can adjust barcode data output format according to the host requirement
Power adapter
5V power adapter with RS232 data line to power the equipment.
Tracing the performance
Image sensor
The CCD
pixel
2500
lighting
Red LED (620nm ~ 630nm)
af
Red leds (620nm ~ 630nm)
Maximum decoding velocity
300 times/SEC.
Read code system
1D AIM 128, Code 11, Code32, Code 39, Code 93, Code 128, Codabar, COOP 25, Deutsche 12, Deutsche 14, EAN -8, ISBN, GS1 -128, GS1 -128, GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1 -128, the GS1, the "s,", the "s", the "s", "the", "the", "the", "the", "the", "the", "the", "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "" "
Accuracy of literacy
3 mil
Barcode sensitivity * *
tilt
Plus or minus 60 °
Deflection (skew)
+ 70 °
Typical reading depth *
Code 39 (5mil) 80mm ~ 180mm
EAN 13 (13mil) 40mm ~ 480mm
The view point of
53 ° plus or minus 2 °
Symbol contrast
20% or higher
Mechanical /
Electrical parameters
Communication interface
RS232, USB, PS / 2 (optional)
prompt
Buzzer, LED indicator
Appearance size (mm)
145 (W) x 101 (D) x 68 (H)
Working voltage
5 VDC plus or minus 5%
The weight of the
120 g
The rated power
345mW (typical value)
Current @ 5 VDC
Working current
70.4 mA (typical value), 96.8 mA (maximum)
Standby current
57.6 mA
Environmental parameters
Working temperature
- 20 ℃ ~ + 60 ℃
Storage temperature
- 40 ℃ ~ + 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 16kV (air discharge), plus or minus 8 kV (direct discharge)
Drop height
1.5 meters
Protection grade
IP42
International certification
FCC Part15 Class B, CE EMC Class B
Accessories list
cable
USB
The RS - 232.
PS / 2
USB cable to connect to the machine and to receive the host.
The RS232 data line is used to connect the machine and the information receiving host.
PS / 2 data line used to connect the machine and the information receiving host.
stents
Smart stent
The device is used to support the intelligent switching scanning mode.
Data editing function
Support, can adjust barcode data output format according to the host requirement
Power adapter
5V power adapter with RS232 data line to power the equipment.
