The performance parameters
The light source
Red LED (610nm ~ 640nm)
Code of literacy 1D
EAN - 13, EAN - 8, upc-a, upc-e, ISSN, ISBN, Codabar, Code 128, Code 93, itf-6, itf-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, msi-plessey, Plessey
Read the precision
P 5 mil
Barcode sensitivity * *
tilt
Plus or minus 60 ° @ 0 ° Roll and 0 ° Skew
rotating
Plus or minus 30 ° @ 0 ° Pitch and 0 ° Skew
deflection
Plus or minus 60 ° @ 0 ° Roll and 0 ° Pitch
Minimum contrast
The reflection difference is greater than 30%
Scanning speed
300 times/SEC.
Data interface
USB
Mechanical/electrical properties
Scanner size (length x width x height)
160 * 95 * 65 mm
Scanner weight
220 grams (including USB cable)
prompt
Buzzer, LED indicator
The power supply
DC5V
current
Maximum current
< 130 ma,
Working current
60 ma + 10 ma,
Standby current
15 ma + 5 ma
The trigger life
1 million times
Environmental parameters
Working temperature
- 20 ° C ~ + 50 ° C
Storage temperature
To 40 ° C to + 70 ° C
Relative humidity
5% ~ 95% (no condensation)
certification
* * test conditions: Code 39, 3 Bytes; Minimum width = 10mil; The width is 3:1; PCS = 0.8; Bar code height = 11mm; Test distance = 120mm; The environment temperature = 23 ℃; Ambient illumination = 300 LUX
