Physical parameters

Size: 16.5 cm H x 9.8 cm W x 6.7 cm D

Weight (excluding cable) : 5.7 ounces / 162 grams

Power: 5VDC + -10%, 360mA (typical RMS)

Color: light black

Supported interfaces: USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485

The performance parameters

Light source: focusing mode: 617nm LED

Lighting: 660 nm LED

Imaging area: 23.3 ° (horizontal) x 14.7 ° (vertical)

Minimum print contrast: 20%

Rotate/tilt Angle offset perspective: + / - 360 °, + / - 65 °, + / - 65 °

Resolution: Code 39:2 mil; Code 128:2 mil; DataMatrix: 3 mil

Decoding ability

1 dimension: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

2d: PDF417, Micro PDF417, Composite Codes, tlc-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes

Using the environment

Working temperature: 32 ° F to 122 ° F / 0 ° C to 50 ° C

Storage temperature: - 40 ° F to 158 ° F/to 40 ° C to 70 ° C

Humidity: relative humidity 5% to 95%, no condensation

Fall specification: can withstand the impact of several times from the height of 6 feet / 1.83 meters to the concrete floor

Seal: IP42

Anti-light: anti-normal indoor light, up to 1600 lux; Anti-japanese light, up to 86000 lux

The attachment

Optional: smart bracket Gooseneck Intellistand

DS3408XD decoding range

Code 39, 2 mil, 1.27 cm-7.62 cm

Code 39, 3 mil, 0.5 cm - 9.65 cm

Code 39, 5 mil, 0.25 cm-11.94 cm

Code 128, 2 mil, 1.52 cm-7.62 cm

Code 128, 3 mil, 1.02 cm - 8.34 cm

Data Matrix, 4 mil, 1.8 cm - 7.62 cm

Data Matrix, 5 mil, 1.02 cm-8.64 cm

Datamatrix, 10 mil, 0.25 cm-11.68 cm

QR Code, 10 mil, 0 cm-11.43 cm

PDF417, 4 mil, 1.27 cm-8.34 cm

PDF417, 5 mil, 0.25 cm-9.14 cm

PDF417, 6.67 mil, 0.25 cm-10.41 cm
