Physical parameters

Size: 16.8 cm H x 6.6 cm W x 10.7 cm D

Weight (excluding cable) : 5.4 ounces / 154 g

Input voltage range: 4.5 to 5.5 VDC

Current: 450 ma

Color: white, black

Supported host interface: USB, RS232, keyboard port, TGCS (IBM) 46XX over RS485

Keyboard support: more than 90 international keyboards

User instruction: direct decoding instruction, successfully decoding LED, rear view LED, buzzer (adjustable tone and volume)

The performance parameters

Light source: focus mode: round 617nm amber LED

Lighting: 645nm red LEDs

Imaging area: 48 ° (horizontal) x 37 ° (vertical), rated

Image sensor: 1280 x 960 pixels

Minimum print contrast: 16%

Rotate/tilt Angle offset perspective: + / - 360 °, + / - 60 °, + / - 60 °

Imaging parameters

Supported image format: can export images in Bitmap, JPEG, or TIFF format

Image quality: A4 document

Resolution: Code 39-3.0 mil; Code 128-3.0 mil; Data mAtrix - 6.0 mil; QR Code - 6.0 mil

Decoding ability

1 dimension: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

2d: PDF417, Micro PDF417, Composite Codes, tlc-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes

Digimarc: digital watermarking technology

Using the environment

Working temperature: 32 ° F to 122 ° F / 0 ° C to 50 ° C

Storage temperature: - 40 ° F to 158 ° F/to 40 ° C to 70 ° C

Humidity: relative humidity 5% to 95%, no condensation

Drop specification: can withstand more than 50 shocks from 6.0 feet / 1.8 meters to the concrete floor

Rolling specification: can withstand the impact of the rolling of 1.5ft / 0.5 m

Seal: IP42

Light resistance: 0 to 96840 Lux

Electrostatic discharge: : ESD per en61000-4-2, + / -15 KV (air), + / -8 KV (direct), + / -8 KV (indirect)

Tools and maintenance

123Scan: set the scanner parameter and update firmware

Scanner SDK: used to generate a fully functional Scanner program

Scanner Management Service (SMS) : remote administration

Decoding the scope

Code 39, 3 mil, 5.6 cm - 12.7 cm

Code 39, 20 mil, 0 cm - 93.5 cm

Code 128,3mil, 6.6 cm - 11.4 cm

Code 128,5mil, 4.1 cm - 21.3 cm

Code 128,15 mil, 0.0 cm - 68.8 cm

PDF417, 5 mil, 5.8 cm - 16.3 cm

PDF417, 6.7 mil, 4.6 cm - 21.6 cm

UPC, 13 mil (100%), 0.0 cm - 61.0 cm

Data Matrix, 7.5 mil, 5.3 cm - 17.5 cm

Data Matrix, 10 mil, 2.8cm - 25.1cm

QR, 20 mil, 0.3cm - 44.7 cm
