Physical parameters

Size: host: 16.8 cm H x 6.6 cm W x 10.7 cm D; Standard charging base: 7.1 cm H x 8.4 cm W x 21.1 cm D; No charging base: 7.4 cm H x 9.4 cm W x 12.2 cm D

Weight: host: 8.3 ounces / 235.3 grams; Charging base: 7.1 oz / 202 g; Rechargeable seats: 6.5 ounces / 182 grams

Input voltage range: charging base 5V: 4.7 to 5.5 VDC; 12V: 10.8 to 13.2 VDC

Current: charging base: 470 mA (typical) standard USB; 743mA (typical) 12V

Color: white, black

Supported host interface: USB, RS232, keyboard port, TGCS (IBM) 46XX over RS485

Keyboard support: more than 90 international keyboards

Instructions: direct decoding instructions, successful decoding LED, rear sight LED, buzzer (adjustable tone and volume), battery instructions

The performance parameters

Light source: focus mode: round 617nm amber LED

Lighting: 645nm red LEDs

Imaging area: 48 ° (horizontal) x 37 ° (vertical), rated

Image sensor: 1280 x 960 pixels

Minimum print contrast: 16%

Rotate/tilt Angle offset perspective: + / - 360 °, + / - 60 °, + / - 60 °

Imaging parameters

Supported image format: can export images in Bitmap, JPEG, or TIFF format

Image quality: A4 document

Resolution: Code 39-3.0 mil; Code 128-3.0 mil; Data mAtrix - 6.0 mil; QR Code - 6.0 mil

Decoding ability

1 dimension: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

2d: PDF417, Micro PDF417, Composite Codes, tlc-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes

Digimarc: digital watermarking technology

Using the environment

Working temperature: 32 ° F to 122 ° F / 0 ° C to 50 ° C

Storage temperature: - 40 ° F to 158 ° F/to 40 ° C to 70 ° C

Humidity: relative humidity 5% to 95%, no condensation

Drop specification: can withstand more than 50 shocks from 6.0 feet / 1.8 meters to the concrete floor

Rolling specification: can withstand the impact of the rolling of 1.5ft / 0.5 m

Seal: IP42

Light resistance: 0 to 96840 Lux

Electrostatic discharge: : ESD per en61000-4-2, + / -15 KV (air), + / -8 KV (direct), + / -8 KV (indirect)

Radio specifications

Bluetooth rf: standard bluetooth version 4.0, with BLE: Class 1, 330 feet (100 meters) and Class 2 33 feet (10 meters), serial port and HID procreate

Adjustable bluetooth power supply: Class 1: the output power can be adjusted downward from 4 DBM by 8 gradients; Class 2: the output power can be adjusted downward from 2 DBM by 8 gradients

The battery

Battery capacity/battery type: 2500 mAh lithium ion Power Precision + battery

Scan frequency after each charge: 65000 times per minute scan

Working hours after each charge: 83 hours

Charge time (from battery to empty) to full charge (hours) :

Standard USB: use charging base: 7 hours 45 minutes, use free charging seat: 9 hours 15 minutes

BC1.2 USB: use charging base: 3 hours, use free charging seat: 3 hours 15 minutes

External 5V power source: use charging base: 4 hours 30 minutes, use free charging seat: 5 hours

External 12V power supply: use charging base: 2 hours 15 minutes, use free charging seat: 2 hours 15 minutes

The attachment

Standard charging pedestal, free rechargeable seat, wall mount bracket, spare battery, document acquisition bracket

Tools and maintenance

123Scan: set the scanner parameter and update firmware

Scanner SDK: used to generate a fully functional Scanner program

Scanner Management Service (SMS) : remote administration

Decoding the scope

Code 39, 3 mil, 5.6 cm - 12.7 cm

Code 39, 20 mil, 0 cm - 93.5 cm

Code 128,3mil, 6.6 cm - 11.4 cm

Code 128,5mil, 4.1 cm - 21.3 cm

Code 128,15 mil, 0.0 cm - 68.8 cm

PDF417, 5 mil, 5.8 cm - 16.3 cm

PDF417, 6.7 mil, 4.6 cm - 21.6 cm

UPC, 13 mil (100%), 0.0 cm - 61.0 cm

Data Matrix, 7.5 mil, 5.3 cm - 17.5 cm

Data Matrix, 10 mil, 2.8cm - 25.1cm

QR, 20 mil, 0.3cm - 44.7 cm
