Physical size
Size: 6.30 inches (high) x 2.64 inches (wide) x 3.90 inches (thick)
Weight: 4.95 ounces / 140 grams
Voltage and current: 5VDC plus or minus 10%, < 165 mA scan, < 40 mA standby, < 2.5 mA USB suspension, < 4.0 mA low power mode (when enabled, only RS232 and keyboard socket)
Power supply: power source or external power supply
Color: light black; Cash register white
Supported host interfaces: USB, RS232, keyboard socket, and IBM RS485
Keyboard support: more than 90 international keyboards
The performance parameters
The offset Angle tolerance: + 65 °
The tilt Angle tolerance: + 65 °
The rotating Angle tolerance: plus or minus 45 °
Scanning mode: single bright line of sight
Scanning Angle: horizontal 35 °
Scan speed: 547 scans per second
Mobile tolerance: 25 inches (63.5 cm)/second
Light source: lED Class 1 equipment (617 nm) (tan)
Minimum print contrast: 15% MRD
条码符号:UPC/EAN: UPC-A、UPC-E、UPC-E1、EAN-8/JAN 8、EAN-13/JAN 13、Bookland EAN、Bookland ISBN Format、UCC Coupon Extended Code、ISSN EAN Code128 Including GS1-128、ISBT 128、ISBT Concatenation、Code 39 including Trioptic Code 39、Convert Code 39 to Code 32 (Italian Pharmacy Code)、Code 39 Full ASCII Conversion、Code 93、Code 11、Matrix 2 of 5、Interleaved 2 of 5 (ITF)、Discrete 2 of 5 (DTF)、Codabar (NW - 7)、MSI、Chinese 2 of 5、IATA、Inverse 1D (except all GS1 DataBars)、GS1 DataBar including GS1 DataBar-14、GS1 DataBar Limited、GS1 DataBar Expanded
Decoding scope (standard work scope *)
3 mil: minimum resolution
4 mil: 4-10 inches / 10.2-25.4 cm
5 mil: 3-13 inches / 7.6-33 cm
7.5 mil: 1.5-19 inches / 3.8-48.3 cm
13 mil: (100% UPC - A) : 1-31 inches / 2.5-78.7 cm
20 mil: 1-42 inches / 2.5-106.7 cm
26 mil: (200% UPC - A) 3-55 inches / 7.6-140 cm
100 mil: reflection > 20ft / 6m
* the working scope is tested within 30 feet of ambient lighting conditions; Fan wai is calculated by Code 39 (unless otherwise stated)
Utilities and management
123Scan2, scanner management service (SMS), MOTOROLA scanner SDK
Using the environment
Anti-ambient light: no interference from indoor normal artificial lighting conditions and outdoor natural lighting conditions (direct sunlight). Fluorescent lamp, incandescent lamp, mercury vapor lamp, sodium vapor lamp, LED: 450 Ft (4,844 Lux); Daylight: 8000 Ft (86,111 Lux)
Working temperature: 32 ° F to 122 ° F / 0 ° C to 50 ° C
Storage temperature: - 40 ° F to 158 ° F/to 40 ° C to 70 ° C
Humidity: 5% to 95% (no condensation)
Drop specification: at room temperature, it can withstand more than 100 falls from 5 feet / 1.5 meters, and can withstand the impact of falling from 6 feet / 1.8 meters to the concrete floor
Rolling test: rolling 1000 weeks in a half-meter high roller (equivalent to 2,000 falls)
Environmental seal: IP42
The attachment
(gooseneck) Intellistand; Automatic host detection cable
