Physical/environmental parameters
Size: 157 mm * 57 mm * 41 mm
Weight: 231g (including standard battery pack)
Operating temperature: - 10 ℃ to 50 ℃
Storage temperature: - 20 ℃ to 70 ℃
Relative humidity: 5% - 95% (no condensation)
Impact strength: it can withstand repeated falls from 1.2 meters to cement floors within the operating temperature range
Roll test: 500 (1000 collisions) within 1 meter diameter
Industrial grade: IP54
Anti-static: direct contact discharge with plus or minus 8kV; Plus or minus 15kV air discharge
System parameters
CPU: Marvell XScale PXA300 624MHZ
Operating system: Microsoft Windows ce5.0 Core
Memory: 64MB RAM, 128MB Flash
Screen: 2.4 inches QVGA (240 * 320) with touch screen option,
Keyboard: 28 key digital key (letter/switch/function key/navigation key)
Audio: available speakers
I/O interface: full speed USB1.1 base (or I/O cable); RS232 (115kbs) base
Application: Honeywell Powertools and demo software
Development environment: Honeywell SDK for Windows CE5.0
Storage extension: 32gb Micro SD card
Battery: the default 2200mAh lithium battery can be expanded to 3300mAh high-capacity battery
Estimated operating time: more than 8 hours (continuous scanning and data transmission)
Estimated time of charge: less than 4 hours
Scanning head: Honeywell laser or image engine
Decoding function: a two-dimensional symbol system for the reading standard
Warranty period: one year (including terminals and accessories)
Wireless parameters
WLAN: dual mode 802.11b/g (11Mbp / 54Mbps) built-in antenna
WLAN safety standards: WEP, WPA, WPA2
WPAN: Bluetooth ClassII (10m)
