Honeywell Dolphin's 6100 mobile data collector

Dolphin's 6100 mobile data collector

Brand: Honeywell
Model: Dolphin 6100
Main features of the product:
The noil line is smooth and user friendly design
Stylish, airy fuselage is suitable for intensive data entry, even if the single hand operation is comfortable.
Noil wireless real-time communication
Advanced 802.11b/g and bluetooth wireless communication technology, capable of transmitting important data in real time and supporting advanced wireless security standard protocol.
A powerful software tool
Equipped with a series of simple and practical software tools to simplify machine setup, application development and remote device management.
The noil sets a variety of data collection functions in one, the performance is remarkable
With Adaptus 5.0 imaging technology, we can read all standard one and two dimensional bar code and capture digital image to achieve multi-purpose.
It is well designed and durable
The exquisite interior design enables it to be reliably applied to light industrial environments.

DetailParameterDownloadVideo data

Physical/environmental parameters

Size: standard battery: 175mm * 66mm * 26.8mm; Enhanced battery: 175mm * 69mm * 43mm. Handle: 58 mm

Weight: 250g includes battery pack and wrist strap; Laser: standard battery: 252g, enhanced battery: 275g.

Operating temperature: image type: - 10 ℃ to 50 ℃; Laser: - 10 ℃ to 50 ℃

Storage temperature: - 20 ℃ to 70 ℃

Relative humidity: 95% (no condensation)

Impact strength: it can withstand repeated falls from 1.2 meters to cement floors within the operating temperature range

Roll test: 500 (1000 collisions) within 1 meter diameter

Industrial grade: IP54

Anti-static: + 8kV contact discharge; Plus or minus 15kV air discharge

System parameters

CPU: Marvell XScale PXA300 624MHZ

Operating system: Microsoft Windows ce5.0, Windows Embedded Handheld6.5

Memory: Windows ce5.0:128MB RAM, 128MB Flash; Windows Embedded Handheld6.5:256MB RAM, 256MB Flash

Display: 2.8 inch 65000 color transmission active matrix color liquid crystal display, with backlight, QVGA (240 * 320)

Keyboard: 28 keys to the alphabet keyboard

Voice communication: equipped with VoIP voice function and one-click access

Voice interface: built-in microphone, speaker and stereo headphone jack

Communication interface: full speed USB1.1 base (or I/O cable); RS232 (115kbs) base

Application: Honeywell Powertools and demo software

Development environment: Honeywell SDK for Windows CE5.0; Honeywell SDK for Windows Embedded Handheld6.5 and Visual Studio 2008

Third-party software: SOTI MobiControl (remote device management), Naurtech ETerm terminal simulation, ITScripNet

Battery: standard: lithium battery, 3.7 V, 3300mAh (12.2 Wh); Enhanced: lithium battery, 3.7 V, 3300mAh (including enhanced battery cover)

Estimated operating time: 8 hours (continuous scanning and data transmission)

Estimated time of charge: less than 4 hours

Scan head: image head: 5100SF, 5100HD, 5300SR, and 5300HD with Adaptus technology aiming line; Laser head: IS4813

Decoding function: image scanning engine: reading standard one-dimensional and two-dimensional code; Laser scanning engine: read standard one-dimensional code

Warranty period: one year (including terminals and accessories)

Wireless parameters

WLAN: dual mode 802.11b/g (11Mbp / 54Mbps) built-in antenna

WLAN safety standards: WEP, 802.1 x, LEAP, TKIP, MD5, EAP - TLS, EAP - TTLS, WPA - PSK, WPA v2.0, PEAP, CCx4

WPAN: Bluetooth ClassII (10m)
