Physical/environmental parameters
Size: BT&BT/WLAN configuration: 178mm * 69mm * 42mm; GSM configuration: 180mm * 69mm * 47mm
Weight: BT&BT/WLAN configuration: about 332g; GSM configuration: about 406g.
Operating temperature: - 10 ℃ to 50 ℃
Charging temperature: 0 ℃ to 40 ℃
Relative humidity: 95% (no condensation)
Impact strength: it can withstand repeated falls from 1.5 meters to the cement floor in the operating temperature range
Industrial grade: IP54
Anti-static: + 8kV contact discharge; Plus or minus 12kV air discharge
System construction
CPU: Samsung 2440 400MHZ
Operating system: BT&BT/WLAN configuration: Microsoft Windows ce5.0 or Windows Mobile6.0 Classic; GSM configuration: Windows Mobile6.0
Memory: 128MB RAM, 128MB Flash
Screen: 2.8in 1/4 VGA (240 * 320 pixels) TFT color display touch screen
Memory extensions: Windows CE configuration: a memory expansion slot that is available for use by the user, applicable to SD or MMC flash memory CARDS; Windows Mobile configuration: user accessible microSD/microSDHC
Battery: 3.7 V / 2200mAh / 8.1 Wh lithium battery (standard configuration); 3.7 V / 3240mAh / 12Wh lithium battery (optional);
Engine/scanner: 5300SR with high resolution frame sight.
Decoding ability: can read one and two dimensional barcode.
Keyboard: 29 key digital - transalphabetic keyboard, 6 programmable function keys, backlight; The 38-key alphanumeric keyboard, 2 programmable keys, backlight
Sound/voice: built-in microphone, speaker, standard 2.5mm headset
Communication: RS - 232 / USB interface, infrared transmission port
Development environment: Honeywell SDK for Windows Mobile6.0
Third-party software: SOTI MobiControl (remote device management), Naurtech ETerm terminal simulation, ITScripNet
Wireless parameters
WWAN: quad-frequency: GSM 850/900/1800/1900MHz, GSM version 99, EDGE multislot Class12, GPRS Class12
WLAN: dual mode 802.11b/g (11Mbp / 54Mbps) built-in antenna
WLAN safety standards: WEP, 802.1 x, LEAP, TKIP, MD5, EAP - TLS, EAP - TTLS, WPA - PSK, WPA v2.0, PEAP, CCx4
WPAN: Bluetooth ClassII (10m)
GPS: equipped with GPS (GPS) receiver, built-in antenna supports SIRFstarll technology.
