Honeywell MS3780 full-line laser barcode scanner

MS3780 full - line laser barcode scanner

Brand: Honeywell
Model: Voyager 95X0
Main features of the product:
The IP54 industry level: protects the scanner from dust particles and jets of water.
Ergonomic design: suitable for various hand grips.
Strong and durable housing design: it can withstand repeated falls in the air from 2 meters to the ground, reducing downtime and maintenance costs.
100 scans per second: faster and faster scanning.
The automatic detection function of supports: flexible switching of hand-held or fixed scanning.

DetailParameterDownloadVideo data

Physical parameters

Size: 18.9 cm height x 6.5 cm long x 7.3 cm wide

Weight (excluding cable) : 195 grams

The performance parameters

Light source: visible laser diode laser, wavelength of 650nm plus or minus 10nm

Beeper: 7 tones or silenced

Indicator light: blue = laser light, ready to scan; White = decoded successfully

System interface: USB, RS232, keyboard port, RS485

Scan mode: all-directional multi-line (5 directions, 4 parallel lines in each direction); Button triggers single line mode

Scanning speed: full to multiple lines: 1333 times per second; Single line: 67 times/s

Recognizable print contrast: a minimum of 35% reflection

Angle, elevation, partial degrees: 360 °, 60 °, 60 °

Decoding ability: UPC, EAN, UPC, EAN with Supplementals, UCC. EAN 13, 128, JAN 8 & Code 39, 39 Full ASCII Code, Code 39 Trioptic, Code 128, 128 Full ASCII Code, Codabar (NW7), Interleaved 2 of 5, Discrete '2 of 5, 93, MSI, Code 11 Code, Code 32, Bookland EAN, IATA, UCC/EAN RSS and RSS variants

Using the environment

Working temperature: host: 0 ° C to 40 ° C

Storage temperature: host: - 40 ° to 60 ° C C

Humidity: relative humidity 5% to 95%, no condensation

Earthquake resistant capacity: main engine: can withstand 1.5 m repeatedly fall (to concrete floor)

Light level: 0 to 4842lux

Dust proof: seal to prevent air dust from erosion

Electrical parameters

Input voltage: 5VDC + 0.25v

Working power: 1.4 W (275mA, 5VDC)

Standby power: 1W (200mA, 5VDC)

Laser level: Class1

MS3780 decoding region:

The barcode width is deep

Code39-5.2 mil 44 mm - 108 mm

Code39-7.5 mil 25 mm - 190 mm

Code39-10.4 mil 25 mm - 240 mm

Code39-13 mil 25 mm - 280 mm

Code39-21 mil 25 mm - 300 mm
