Honeywell MS9590i/MS9591i industrial single-line laser barcode scanner

MS9590i/MS9591i industrial single-line laser barcode scanner

Brand: Honeywell
Model: MS9590i/MS9591i
Main features of the product:
The IP54 industry level: protects the scanner from dust particles and jets of water.
Ergonomic design: suitable for various hand grips.
Strong and durable housing design: it can withstand repeated falls in the air from 2 meters to the ground, reducing downtime and maintenance costs.
100 scans per second: faster and faster scanning.
The automatic detection function of supports: flexible switching of hand-held or fixed scanning.

DetailParameterDownloadVideo data

Physical parameters

Size: 16cm height x 6.5 cm long x 10 cm wide

Weight (excluding cable) : 150 grams

The performance parameters

Light source: visible laser diode laser, wavelength of 650nm plus or minus 10nm

Beeper: 7 tones or silenced

Indicator light: blue = upper point, ready for scanning; White = decoded success; Yellow = automatic scanning in support

System interface: USB, RS232, keyboard port, RS485

Scan type: single line

Scanning speed: 100 times per second

Scanning Angle: horizontal ° 44

Recognizable print contrast: a minimum of 35% reflection

Angle, elevation, partial degrees: 42 °, 68 °, 52 °

Decoding ability: UPC, EAN, UPC, EAN with Supplementals, UCC. EAN 13, 128, JAN 8 & Code 39, 39 Full ASCII Code, Code 39 Trioptic, Code 128, 128 Full ASCII Code, Codabar (NW7), Interleaved 2 of 5, Discrete '2 of 5, 93, MSI, Code 11 Code, Code 32, Bookland EAN, IATA, UCC/EAN RSS and RSS variants

Using the environment

Working temperature: host: 0 ° C to 40 ° C

Storage temperature: host: - 40 ° to 60 ° C C

Humidity: relative humidity 5% to 95%, no condensation

Earthquake resistance: main engine: can withstand the repeated fall of 2m (to concrete floor)

Light level: 0 to 4842lux

Seal level: IP54

Electrical parameters

Input voltage: 5VDC + 0.25v

Working power: 650mW (130mA, 5VDC)

Standby power: 375W (0.75a, 5VDC)

Laser level: Class1

MS9590i/MS9591i decoding area:

Bar code width MS9590i MS9591i

Code39-4mil cannot read 25mm-45mm

Code39-5.2 mil 83 mm - 108 mm and 22 mm and 55 mm

Code39-7.5 mil 38 mm - 178 mm; 20 mm - 64 - mm

Code39-10.4 mil 32 mm - 254 mm 0 mm - 72 mm

Code39-13 mil 0 0 mm mm - 305 mm - 100 mm

Code39 unmeasured - 26 mil 12 mm - 445 mm
