Print specifications
Way of print
Heat transfer/heat sensitive type
The printing speed
2 ~ 6 inch/s
Print interface
USB port
Print head resolution
203 dots per inch (eight dots/mm)
Print mode
Carbon ribbon/heat sensitive
Printing point size
X0.125 0.125 mm (1 mm = 8 dots)
Maximum print width
104 mm or 104 mm
Maximum print length
2286 mm (2286 °)
The general specification
Printer size
278 x210x180 (WxDxH)
Printer weight
2.09 KG
The operating environment
41 ~ 5 ~ 45 ℃ (104 ℉), 25 ~ 85% no condensation
Storage environment
- 10 ~ 50 ℃ (10 ~ 104 ℉), 10 ~ 90% no condensation
Pulse excitation
1 x108pulses
Thermal film (wear resistance)
30 km
The power supply
Input: AC 110V / 240v.output: DC24V / 2.5v, 60W
accessories
Optional external support
Carbon with specifications
Carbon with outer diameter
Maximum 67 mm
Carbon belt length
300 m
Carbon belt axial size
1 inch (2.54 mm)
Carbon belt width
Max. 110 mm, Min. 30 mm
Carbon tape winding form
The volume type
Paper specifications
Built-in volume maximum outer diameter
127mm (5 ') OD
The paper type
Continuous paper, gap paper, folding paper, black label paper
Paper winding form
Print the external volume
Paper width (label + bottom paper)
Maximum 120mm (4.72 ') minimum 20mm (0.78 ')
Paper thickness (label + bottom paper)
Maximum 0.254 mm (10mil) minimum 0.06 mm (2.36 mil)
Paper scroll core size
25.4 mm ~ 38 mm (1.5 ' ' ' '~ 1)
Interval height of gap paper
Minimum 2mm (0.09 ')
The length of the label
Note: if the length of the label you are using is less than 25.4 mm (1 'prime'), it is recommended that you use the label paper on the gap to tear apart
