print
Way of print
Direct line heat sensitivity
Print width
48 mm
Point density
The 384 - point/line
The printing speed
60mm/SEC
The interface type
Serial port/USB/parallel port
Printing paper
Paper paper width: 57.5 + / - 0.5 mm, outside diameter: 65 mm Φ
Line spacing
3.75mm (adjustable line spacing with commands)
The number of columns
Font A - 32 columns/Font B - 43 columns/simple, complex - 16 columns
Character size
ANK character, Font A: 1.5x 3.0mm (12x24)
Font size: 1.1 x 2.1 mm (9 x 17 points)
Simplified/traditional: 3.0 x 3.0 mm (24 x 24 points)
The bar code characters
Extended character sheet
PC437 / Katakana/PC850 / PC860 / PC863 / PC865 / West Europe/Greek, Hebrew/East Europe/irfan/WPC1252 / PC866 / PC852 / PC858 / IranII/Latvian /
Arabic/PT151, 1251 / PC737 / WPC / 1257 / Thai one/PC864 / PC1001 / (Latvian)/(PC1001)/(PT151, 1251)
(WPC1257)/(PC864)/(one)/(Thai)
Bar code type
UPC - A/UPC - E/JAN13 (EAN13)/JAN8 (EAN8) CODE39 ITF/CODABAR/CODE93 / CODE128
character
Standard GB2312 simplified Chinese
The buffer
The input buffer
4 k bytes
NV Flash
60 k bytes
The power supply
Cashbox output
DC 12 v / 1 a
Power adapter input: AC 110V / 220V, 50 ~ 60Hz output: DC 8.5/3A
Power DC8.5 V / 3 a
Physical properties
The weight of the
0.83 kg
Appearance of size
198 times 125 by 99 millimeters (L by W by H)
Environmental elements
The work environment
Temperature: 5 ~ 45 ℃, humidity: 10-80%
Storage environment
Temperature: - 10 ~ 50 ℃ humidity: 10-90% (condensation)
life
reliability
50 km
