print
Way of print
thermal
The resolution of the
203 dpi
Print width
80 mm
The printing speed
Maximum 8 inch/s; Ordinary 4 inch/s
memory
DRAM: 8M FLASH: 4M
Print head temperature detection
thermistor
Print head location detection
Micro switch
Paper detection
Photoelectric sensor
Communication interface
USB
The barcode
character
graphics
The barcode
CODE128, EAN128, ITF,
CODE39, CODE93, EAN13,
EAN13 + 2, EAN13 + 5, EAN8,
EAN8 + 2, EAN8 + 5, CODABAR,
POSTNET, upc-a, upc-a + 2,
Upc-a + 5, upc-e, upc-e + 2,
Upc-e + 5, CPOST, MSI,
MSIC, PLESSEY, ITF14, EAN14
2d barcode: QRCODE
Character set
Use single verse: FONT 0 to FONT 8
Character amplification/rotation
Transverse longitudinal all but 1-10 x magnification, rotary printing (0 ° and 90 °, 270 °, 360 °),
graphics
Monochrome PCX, BMP and other image files can be downloaded to FLASH, DRAM
medium
The paper type
Heat sensitive roll paper, adhesive paper and so on
Medium width
35 mm to 85 mm
Paper roll diameter
Maximum 115 mm
The way of paper
Tear off
The power supply
The input
24 VDC, 2 a
