Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Printing speed 6IPS (150 mm/s)
Print width 104 mm (4.09 inch)
Print length min.4 mm (0.16 inch); Max. 2540 mm (100 inches)
Memory 8MB Flash (with a capacity of 4MB); 16 MB SDRAM
Sensor form reflector: portable left aligned; Transparent sensor: portable left aligned
Material type: continuous paper, spacing label paper, black line mark paper or punch paper, the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003 inch) ~ 0.25 mm (0.01 inch)
The diameter of the paper roll: the maximum diameter of the paper is 203.2mm (8 ") when using 76.2 mm (3 ") paper scrolls, and the maximum diameter is 152.4 mm (6 ") when using the 38.1 mm (1.5-inch) paper scrolls.
Paper reel core: 38.1 mm (1.5 ") ~ 76.2 mm (3 ")
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 450 m (1,471 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum external diameter: 76 mm (2.99 ")
C core: 25.4 mm (1 inch)
The program language, EZPL, GEPL. Automatic switching
Random software label typesetting software: QLabel - IV/GoLabel (supporting EZPL only)
Driver & DLL: supports Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap font print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download font Bitmap fonts downloadable: 6, 8, 10, 12, 14, 18, 24, 30, 16 x26 and OCR A & B, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector (the vera.ttf font), the print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, the Code 93, 8/13 (add on 2 & 5) EAN, UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), 128, EAN RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)
Graphics processing support monochrome PCX, BMP, and other diagram types can be supported by software control
Port of communication: rs-232 (DB - 9)
The USB port
10/100 MBPS Ethernet print server
Control panel three monochrome LED indicator lights: Power on, Ribbon out, Media out
Three sets of multifunctional hardware control keys: FEED, PAUSE and CANCEL
The paper detects the calibration key
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
The timing device is built in standard
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, cUL, CCC
Body size: 512 mm (20.15 ")
Height: 291 mm (11.45in)
Width: 274 mm (10.78 inch)
The body weighs 15 kg (33 pounds) with no other materials or options.
Select the knife of the purchase item
Automatic stripping and backpaper recyclers
The Parallel Port (IEEE1284) connection Port
Automatic pasting machine interface connecting line (1 input, 3 outputs, power 500mA @ 5V)
External paper holder (the maximum paper diameter is 10 inches)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
* * in response to different consumables, the actual printing size should be determined by the actual consumables.
