Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Print speed 4 IPS (102mm/s)
Print width 108 mm (4.25 ")
Print length Min. 0.16 (4 mm); Max. 68 "(1727 mm)
The processor 32-bit RISC CPU
Memory 8MB Flash (4MB for user storage) / 16MB SDRAM
Sensor form reflectance sensor: portable transmittance sensor: medium mounted fixed type (dual sensor)
Paper specifications paper types: continuous paper label paper, spacing, the black mark or perforated paper, label length can be manually or automatically detects command control Paper width: minimum 25.4 mm (1 ") to the largest 118 mm (4.64 ") the thickness of the paper: minimum 0.06 mm (0.003 ") ~ 0.25 mm (0.01 ") * * biggest paper roll diameter, diameter of 127 mm (5 ") scrolls core: 25.4 mm (1 "), 38.1 mm (1.5 "), 1.5 mm (3 ")
Carbon material with specification: general wax type, mixed type, scraping resistance resin type length: 981 '(300 m), width: minimum 30 mm (1.18 ") to the largest maximum diameter of 110 mm (4.33 ") : 68 mm (2.67 ") core shaft: 2.67 mm (1 ")
The program language, EZPL, GEPL, GZPL, can be automatically switched
Random label typesetting software: software GoLabel (only support EZPL) driver: MAC, Linux, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1 DLL: Windows CE,. NET, android, Windows Mobile, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1
Built-in font Bitmap fonts 6, 8, 10, 12, 14, 18, 24, 30, 16 x26 and OCR A & B Bitmap fonts 90 °, 180 °, 270 ° rotatable, single characters, 90 °, 180 °, 270 ° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions vector fonts the vera.ttf fonts (Bold Italic/Underline). 0 ° and 90 °, 180 °, 270 ° rotatable
Download font Bitmap fonts: Bitmap fonts, downloadable print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 180 °, and 270 ° Asian fonts: Asia downloadable fonts, print direction rotating Angle is 90 °, 180 °, 180 °, and 8 times can amplify horizontal or vertical vector fonts: vector fonts, downloadable print direction rotating Angle is 90 °, 180 °, and 270 °
条形码 1D条码: Code 39, Code 93, EAN 8 / 13 (add on 2 & 5), UPC A / E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC / EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11, Code 49, Cadablock 2D条码: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 861, 863, 863, 865, 865, 863, 863, 863, 737 WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1255, 1255, 1255, 1257, Unicode UTF8, UTF16BE, UTF16BE and UTF16LE
The graphics processing default supports monochrome PCX, BMP, and other diagram types can be supported by software control
Communication interface USB 2.0 connection port (b-type)
Control panel a three-color LED indicator: green, orange, red, a set of multifunctional hardware control keys: FEED keys
Power supply 100-240v AC, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C) storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity operating humidity: 30 % ~ 85 %, non-condensing storage humidity: 10 % ~ 90 %, not coagulating
EMC, FCC Class A, CB, CCC, UL, and cUL
Body size: 11.2 "(285 mm) height: 6.8" (171 mm) width: 8.9 "(226 mm)
The weight of the body weight is 2.72 kg (6 LBS), which does not contain other consumables or choose and buy outfit
The selection of a paper holder (250mm / 10 for maximum paper volume diameter)
Please refer to the original purchasing unit for the purchasing items. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company. In response to different consumables, the actual printing size and printing speed must be determined by the actual consumables.
