Printing mode heat sensitive/heat transfer
Resolution 203dpi (8 point/mm)
Print width Max4.1 (104mm)
Print speed up to 4ips
Print length Max 43 (1092mm)
Memory 8MB SDRAM (7MB user is available)
4MB Flash ROM (3MB user is available)
CPU 32-bit RISC microprocessors
Communication interface standard, rs-232 serial port, USB
The label sensor occupies the left reflex
Display two LED lights
The interface 1 button
Font international standard character set
Five types of in-built digital fonts can range from 0.049 to 0.23 "H (1.25 mm ~ 6.0 mm)
All fonts can be amplified to 24 x 24 four print direction 0 ° ~ 270 ° rotation
Downloadable Windows compatible True Type Soft Fonts
One dimensional barcode PPLA: Code39 Code93, Code128 / subset of A, B and C, Codabar, Interleaved 2 of 5, UPC A/E / 2 and 5 add - on, EAN 13/8, UCC/EAN - 128, UCC/EAN 128 random weight, Postnet, Plessey, HIBC, Telepen, FIM
PPLB: Code39 Code93, Code128 / subset of A, B and C, Codabar, Interleaved 2 of 5, UPC A/E / 2 and 5 add - on 13/8, EAN UCC/EAN - 128, Postnet, Matrix 2 of 5, UCC Code - 128
2d barcode PPLA/PPLB: Maxicode, PDF - 417, Data Matrix
(ECC200 only for X2000V PPLZ), QR Code, Composite codes
Graphic PPLA/PPLB: PCX, BMP, IMG, HEX, GDI, Binary raster (PPLB only)
Instruction set PPLA, PPLB
software
Windows driver (Windows 7 / Win 8 / Win 10/vista/XP)
Label making software - BarTender
Paper type paper roll type, label type (continuous paper, spacing paper, folding paper, ticket, hang... etc.)
Paper size maximum width: 4.25 "(108 mm)
Minimum width: 1.0 "(25.4 mm)
Thickness: 0.0025 "~ 0.01" (0.0635 mm - 0.254 mm)
Maximum external diameter: 4.3 "(109mm)
Shaft size: diameter 1 "(25.4 mm)
The type of carbon belts: waxy, mixed base, resin base (outer carbon strip)
Carbon band width: 25 ~ 110mm
Carbon belt diameter: the maximum diameter of 1.45 (37mm)
Carbon length: 92m
Shaft size: the inner diameter of the axis 0.5 "(12.7 mm).
Power supply general switching power supply
Input: 100V ~ 240V, 1.8 A, 50 ~ 60Hz
Output: 24VDC, 2.5 A, 60W Max
Installation/standard CE, FCC, RoHS, CCC, cTUVus
Operating environment: operating temperature of 4 ℃ ~ 38 ℃, relative humidity 10% ~ 90%), storage environment: - 20 ℃ to 50 ℃
Optional accessory spinknife, external paper holder, memory card, clock card, Asian type card (complex, simple, Korean and Japanese)
