The performance parameters
The processor
ARM9 400 MHZ CPU
The operating system
Linux compatible operating system
memory
32 MB SDRAM
128MB FLASH (80MB user storage space)
interface
RS - 232, USB, supports USB charging
Physical parameters
Dimensions (length x width x height)
168.5 x 65 x 39.5 mm (6.6 x 2.5 x 1.5 inches)
The weight of the
270 grams (battery)
display
Level 8 gray color screen, 160 x 160 resolution
The keyboard
26 key digital keyboard with backlight function
instructions
Vibrator, speaker and multi-color LED
The battery
Main battery
3.7 V, 2300mAh, rechargeable lithium polymer battery
Backup battery
3.7 v, 150mAh, rechargeable lithium polymer battery
Power adapter
Output: DC 5V, greater than or equal to 1.5a;
Input: AC 100 ~ 240V, 50 ~ 60Hz
Environmental parameters
Working temperature
- 10 ° C ~ 50 ° C (14 ° F to 122 ° F)
Storage temperature
- 20 ° ~ 60 ° C (C - 4 ° F to 140 ° F)
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
+ 15 KV (air discharge); Plus or minus 8 KV (direct discharge)
Drop height
1.2 meters
Protection grade
IP54
Read mode
1 d Laser (= 6 mil)
1D CCD (= 4 mil)
Code128, EAN - 13, EAN - 8, code-39, upc-a, upc-e, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, etc
2D CMOS (= 5 mil)
All 1D and PDF - 417, QR Code, Data Matrix, Maxicode, Aztec, etc
Wireless communications
WLAN
IEEE 802.11b/g, security support EAP, WEP, WPA, WPA2, 802.1 X
Application software development tools
Microsoft Visual Studio 2005 embedded plug-in and program emulator
certification
FCC Part15 Class B, CE EMC Class B, CCC
accessories
Base, battery, adapter, USB cable
* specifications are subject to change without prior notice
