The performance parameters
The processor
Marvell XScale PXA310, 806MHz CPU
The operating system
Microsoft Windows CE.NET 6.0
memory
256 MB of RAM
128MB ROM system space
2GB user storage
interface
Rs-232, USB 2.0, supports USB charging
Physical parameters
Dimensions (length x width x height)
170.5 x 85 x 54 mm (6.7 x 3.3 x 2.1 inches)
The weight of the
454 g (including battery)
display
The 3.5-inch QVGA has a backlit color touch screen that can be read in the sun
The keyboard
33 key digital keyboard with backlighting function (optional full letter keyboard)
instructions
Vibrator, speaker and multi-color LED
The battery
Main battery
3.7 V, 3300mAh, rechargeable lithium polymer battery
Backup battery
3.7 V, 150mAh, rechargeable lithium polymer battery (support 50 hour data backup)
extension
MicroSD slot
Power adapter
Output: DC 5V, greater than or equal to 1.5a;
Input: AC 100 ~ 240V, 50 ~ 60Hz
Environmental parameters
Working temperature
- 10 ° C ~ 50 ° C (14 ° F to 122 ° F)
Storage temperature
- 20 ° ~ 60 ° C (C - 4 ° F to 140 ° F)
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 15 kV (air discharge), plus or minus 8 kV (direct discharge)
Drop height
1.5 meters
Protection grade
IP65
Read mode
1 d Barcode
Laser (4 mil or higher)
CCD (4 mil or higher)
Code128, EAN - 13, EAN - 8, code-39, upc-a, upc-e, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, etc
The 2 d Barcode
CMOS (5 mil or higher)
All 1D barcode and PDF - 417, QR Code, Data Matrix, Maxicode, Aztec, etc
RFID
HF 13.56 MHz (default iso 14443 A/B) (optional ISO15693)
Wireless communications
WLAN
Summit IEEE 802.11b/g, security support EAP, WEP, WPA, WPA2, 802.1 X
WWAN
2 g
GSM/GPRS (850, 900, 1800, 1900 MHz)
3 g
WCDMA (850, 1800, 2100 MHz) or (900, 1800, 1900, 2100 MHz)
WPAN
Bluetooth Class II V2.0
other
GPS, Camera
certification
FCC Part15 Class B, CE EMC Class B, CCC
accessories
Base, battery, adapter, USB cable, stylus
* specifications are subject to change without prior notice
