The performance parameters
The microprocessor
IOTC 0370 CHIP
Read way
640 x 480 CMOS
interface
Rs-232 (9.6 ~ 115.2 Kbps)/USB 1.1 (HID - KBW, HID - POS)
Read code system
The 2 d
PDF417, Data Matrix, QR Code
1 d
EAN - 8 (with additional code), upc-a (with A plus code), upc-e (with A plus code), ISSN,
ISBN, Codabar, Code 128 (including FNC1, FNC2, FNC3 subset), Code 93,
Itf-6, itf-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5,
Matrix 2 of 5, GS1 Databar, EAN -13 (with additional code), msi-plessey,
Code 39 (including Code 39 FULL ASCII), Code 11, Plessey
Read mode
Inductive reading and continuous reading
Read the precision
10 mil
The light source
White LED
Read the code window
52 mm x 69 mm
Print contrast
30% or higher
The view point of
Angle: 68 °, level: 42 °, vertical: ° 54
Mechanical/electrification characteristics
The power consumption of the largest
1 w
instructions
The buzzer, LED
Dimensions (length x width x height)
127.3 * 111.5 * 94 mm
The weight of the
300 g
The environment
Working temperature
- 10 ° C - + 50 ° C
Storage temperature
- 20 ° C - + 60 ° C
humidity
5%-95% (no condensation)
Ambient light
0 ~ 100000 LUX
certification
FCC Part15 Class B, CE EMC Class B, RoHS, photobiosafety certification
Accessories list
cable
RS232
Rs-232 data line for connection information receiving host with adapter interface.
USB
USB cable for connection information receiving host.
Power adapter
5V power adapter with data line to power the scanner.
The output is: DC5V, 0.5 A; Enter as: AC100 ~ 240V, 50 ~ 60Hz
* specifications are subject to change without prior notice
