Scanning performance
Image sensor
CMOS
pixel
752 * 480
lighting
White LED
Read code system
2D PDF417, Data Matrix, QR Code
1 d EAN 13 (with additional Code), EAN - 8 (with additional Code), UPC - A (with additional Code), UPC - E (with additional Code), ISSN, ISBN, Codabar, Code 128 (including FNC1, FNC2, FNC3 subset), Code 93, ITF - 6, ITF - 14, Interleaved 2 of 5, 2 of 5, Industrial Standard 2 of 5, Matrix 2 of 5, GS1 Databar (RSS - Expand, RSS - Limited, RSS - 14), the Code 39 (including 39 FULL ASCII Code), Code 11, MSI Plessey, Plessey
Accuracy of literacy
Acuity 6.7 mil
Read mode
Induction to read
Barcode sensitivity * *
Tilt (pitch) + 40 °
Rotation (tilt) 360 °
Deflection (skew) plus or minus 30 °
The view point of
Level 68.5 ° and 51.5 ° vertically
Sign contrast
25% or higher
Mechanical/electrical parameters
Communication interface
RS232, USB
Appearance size (mm)
78.2 (W) x 67.2 (D) x 52.3 mm (H)
The weight of the
170 g
prompt
buzzer
Working voltage
5 VDC plus or minus 5%
The rated power
858mW (typical value)
Current @ 5 VDC
Working current 187mA (typical value), 209mA (maximum)
Environmental parameters
Working temperature
- 20 ℃ ~ 60 ℃
Storage temperature
- 40 ℃ ~ + 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 8 kV (air discharge), plus or minus 4 kV (direct discharge)
International certification
FCC Part15 Class B, CE EMC Class B
Accessories list
cable
USB USB cable to connect to the machine and information receiving host
The rs-232 RS232 data line is used to connect the machine and the information receiving host
Power adapter
5V power adapter with RS232 data line to power the equipment
* test conditions: temperature = 23 ℃; Ambient illumination = 300 LUX incandescent lamp; The sample code developed in the new world
* test conditions: test distance = (minimum depth + maximum depth) / 2; The environment temperature = 23 ℃; Ambient illumination = 300 LUX incandescent lamp
The 2 d: QR CODE; 10 Bytes; Minimum width = 15 mil; PCS = 0.8;
* specifications are subject to change without prior notice
