Physical parameters

Dimensions: 19.8 cm long x 7.8 cm wide x 12.7 cm high

Weight (excluding cable) : 13.5 ounces / 378 g

Screen: 320 x 240 QVGA color graphics display

Battery: 2400mAh lithium-ion battery, 3.7 Vdc

Communication interface: USB2.0 host and RS232

Keyboard: 21 key click Numbers and clickable letter keyboard, 4 to the navigation key, with 2 functional keys for application control

Battery charging time: 3 hours full (100%) color: light black/yellow

The performance parameters

CPU: IntelXScale PXA270 312MHZ

Operating system: Microsoft Windows CE5.0

Memory: 64 MB or 64 MB

Application development environment: Microsoft Windows client CE EMDK, Motorola EMDK, MCL Designer V 3.0 (MCL client pre-loaded to MT2070, and licensed)

Using the environment

Working temperature: - 4 ° F to 122 ° F / - 20 ° C to 50 ° C

Storage temperature: - 40 ° F to 160 ° F/to 40 ° C to 70 ° C

Humidity: relative humidity 5% to 95%, no condensation

Earthquake resistance: repeatedly falls from 6 feet / 1.8 meters to the cement floor and can still function normally

Rollout specification: 250 times down from 3.2ft / 1 m (equivalent to 500 falls)

Seal level: IP54

Electrostatic discharge: conforms to 15kV air discharge and 8kV contact discharge specification

Data acquisition options

Selection: 4 configurations: 1D laser scanner, 1D / 2D imaging device, 1D / 2D HD imager, DPM imager

Symbolic decoding ability

1 d: UPC/EAN (UPCA/UPCE/UPCE1 / EAN - 8 / EAN - 13 / JAN - 8 / JAN - 13 plus supplements, ISBN (Bookland), Code 39 (Standard, Full ASCII, UCC/EAN - 128, Concatenated ISBT - 128), Code 93, Codabar/NW7, MSI Plessey, I 2 of 5 (Interleaved 2 of 5 / ITF, Discrete '2 of 5, IATA, the China post with matrix minimum Code), GS1 DataBar (Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded and Expanded Stacked, Inverse), Base 32 (ItalianPharmacode)

2D: tlc-39, Aztec (Standard, Inverse), Maxicode, DataMatrix/ECC 200 (Standard, Inverse), QR code (Standard, Inverse, Micro)

PDF417: PDF417 (Standard, Macro), composite code (cc-a, cc-b, cc-c)

Postal codes: U.S. Postnet and Planet, U.K. Post, Japan Post, Australian Post, Netherlands KIX Code, Royal Mail 4 State Customer, upu fics 4 State Postal, USPS 4CB

Cordless data communication

Bluetooth: 2.4 GhzI level radio - 300 feet (91.44 meters) open

Peripheral equipment and accessories

Communications tower: the single slot only charging of the communication, single slot with bluetooth interface communication, the single slot charging forklift communication, only four slot only charging of the communication bridge, four slot Ethernet communication

Charger: four-slot battery charger

Other accessories: belt leather cover, tabletop bracket, Intellistand

Printer: a third-party printer approved by MOTOROLA

MT2070 decoding region:

Label density mt2070-sl mt2070-sd mt2070-hd

Code39-3mil cannot read the unreadable 12.7 mm-73.66mm

Code39-4mil 2.54 m - 71.12 mm cannot be read undetected

Code39-5 mil 5.08 mm to 134.62 mm to 30.48 mm to 30.48 mm 0 mm to 104.14 mm

Code39 7.5 mil 12.7 mm to 264.16 mm to 5.08 mm to 269.24 mm to 2.54 mm to 139.7 mm

UPC 100% - 13mil 5.08 mm - 556.26 mm - 391.16mm 15.24mm - 154.94 mm

Code39-20mil unknown - 739.14 mm unknown - 589.28 mm unknown - 261.62 mm

Code39-40mil is unknown - 1069.34 mm is not readable

Code39-50mil unknown - 1300.34 mm cannot be read unreadable

PDF - 4mil cannot be read and read 20.32mm-66.04 mm

PDF - 5mil cannot be read unreadable 12.7 mm-76.2 mm

PDF - 6.67 mil cannot be read from 63.5 mm - 154.94 mm 5.08 mm - 91.44 mm

PDF - 10mil cannot read 17.78 mm - 243.84 mm 10.16 mm - 114.3 mm

The PDF - 15mil cannot be read with an unknown - 360.68 mm unknown - 149.86 mm
