physical characteristics
The volume of the battery (length x, width, x height): 23.7, cm, x, 8, cm, x, 5, cm (9.33, in, x, 3.16, in, x, 1.98, in)
Weight: 584 g (19.75 oz) (battery included)
Width: grip area 6.42 cm (2.53 in)
Environment parameter
Operating temperature: standard temperature of the machine: --20 degrees C ~ +60 degrees C (-4 degrees F, ~+140 degrees F), can be briefly exposed to -30 degrees C (-22 degrees F)
Refrigerated version of the machine: -30 degrees C~+60 degrees C (-22 degrees F~+140 degrees F)
Storage temperature: -30 degrees C~+60 degrees C (-22 degrees F~+140 degrees F)
Charging temperature: +5 degrees C~+35 degrees C (+44 degrees F~+95 degrees F)
Relative humidity: no condensation, 95%
Rainproof and dustproof: IP67
Roll resistance specification: according to 60068-2-32 standard, can withstand more than 2000 times within 1 meters of rolling
Fall tolerance: according to MIL-STD 810G standard, can withstand 2.4 meters high to the level of ground fall
According to MIL-STD 810G standard, in the operating temperature range, can withstand 1.8 meters high to cement floor fall
Electrostatic discharge: kV + / - 15 + / - 8 kV direct air discharge, contact discharge
Power Supply
Battery pack: 3.7 V, 5200 mAh, Li-Ion removable, rechargeable
operating system
Microsoft, Windows, Embedded, Handheld, 6.5, Android, 6.x.x, Marshmallow, GMS microprocessor, Texas Instruments 1.5, GHz OMAP, dual core, multi engine processing architecture
Memory and storage: RAM: 2, GB, RAM, ROM: 16, GB flash memory
Storage expansion: customers can contact micro-SD card slot, can be placed in the maximum 32GB memory card
Display
8.9 cm (3.5 in) transmission type VGA, 480 x 640 pixels. 65536 (16-bit, RGB) color, high use resistance touch screen, Corning, Gorilla, LED harden glass display, with excellent durability, LED backlight, ambient light sensor
Standard communications: USB - Full, Speed 2, Host, USB - Full, Speed 2, Client
Software
WINDOWS EMBEDDED HANDHELD 6.5
Equipment management:
SmartSystems Foundation is a non handheld deployment and on-site or remote device management provides a single integrated environment. Also compatible with leading third party device management products. .
ScanNGo facilitates barcode based enterprise level device pre configuration. It can be used to download device management software from Honeywell's independent software developer.
CloneNGo of equipment management software, can support device cloning simple, without the use of pre configured equipment management console.
Support third party MDM solutions
Application development: Honeywell developer Library
Device health monitoring: onboard monitoring core subsystems, including scanning, communications, and battery life
Honeywell enterprise class Client package: terminal emulation and HTML5 browser
Optional launcher: application lockout
ANDROID
Equipment management:
EZ Config facilitates barcode based enterprise level device pre configuration. It can be used to download device management software from Honeywell's independent software developer.
Support third party MDM solutions
Application development: Honeywell developer Library
Device health monitoring: onboard monitoring core subsystems, including scanning, communications, and battery life
Honeywell enterprise class Client package: terminal emulation and HTML5 browser
Optional launcher: application lockout
Integrated wireless device
Wireless LAN: IEEE 802.11a/b/g/n dual band WLAN
Security: WPA and WPA2, Wi-Fi certification, WAPI certification
Authority: IEEE 802.1x
Cisco compatibility: CCXv4
Encryption: WEP (64-, or, 128-bit), AES, TKIP
Wireless PAN: integrated Bluetooth, Power, Class, 1.5, Version 4
Sensor technology
Accelerometer: an embedded accelerometer that supports automation or for application functions, such as screen rotation or system suspension
Voice support
Support VOIP/ / speech recognition application before and after the push to talk; speakers; speakers in 40CM at the back-end >80 db; before the receiver and the front panel microphone, can be used for voice communication headset and voice recording; the hasp type adapter supports corded headset
