Physical parameters
Size: 133 mm * 75 mm * 195 mm
Weight: 335 g
Electrical parameters
Input voltage: 4.0 ~ 5.5 VDC
Operating power: 1.80 (360mA @ 5VDC)
Standby power: 0.75w (150mA, 5VDC)
Host system interface: True RS232
Environmental parameters
Working temperature: - 30 ℃ to 50 ℃
Storage temperature: - 40 ℃ to 70 ℃
Humidity: 0% - 95% relative humidity, noncondensing state
Resistance to fall: within the working temperature range, can withstand 50 falls from the height of 2m to the cement floor
Anti-roll ability: to withstand nearly 5, 000 rolls over a 1m range
Industrial grade: IP65
Light level: near 70000LUX
ESD: plus or minus 20Kv air discharge, plus or minus 8Kv contact discharge
Scanning performance
Scanning mode: single line scan
Scanning Angle: the typical application of 13.5 °
Symbol contrast: 35% grayscale (white background)
Obliquity, oblique Angle and elevation Angle: + 65 °, + 65 °, plus or minus 10 °
Decoding ability: automatically identifies all standard one-dimensional bar codes
