Voyager 1250g single-line one-dimensional laser scanner
Brand: Honeywell
Model: Voyager 1250g
Main features of the product:
1. Easy to use: the mounting of the bracket is quick and easy, and the whole installation procedure is simplified. Ergonomic design reduces the fatigue felt by the application environment of scanning intensity
2. Enhanced scanning pass rate: expanded the depth of field, and simplified the scanning of hard-to-reach items; Provide real target detection and support automatic detection function and configuration
DetailParameterDownloadVideo data
Honeywell Voyager 1250g detail parameters:
Physical parameter
Size: host: 6 cm high, X 16.8 cm long, X 7.4 cm wide
Weight (excluding cable): 133 grams
performance parameter
Light source: visible laser diode laser, wavelength 650nm + 10nm
System interface: USB, RS232, keyboard port, RS485
Scan parameter
Scan type: single line
Scanning speed: 100 times per second
Scanning angle: level 30
Recognizable print contrast: minimum 20% reflection difference
Angle, elevation: 60 degrees, 60 degrees
The decoding ability: UPC.EAN, Supplementals, UPC.EAN with UCC.EAN 128, JAN 8 & 13, Code 39, Code 39 Full ASCII, Code 39 Trioptic, Code 128, Code 128, Full ASCII Codabar (NW7), Interleaved 2 of 5 Discrete 2, of 5, Code 93, MSI, Code 11, Code 32, Bookland EAN, IATA, UCC/EAN RSS and RSS variants
Using environment
Operating temperature: host: 0 degrees C to 40 degrees C
Storage temperature: host: -20 degrees C to 60 degrees C
Humidity: relative humidity 5% to 95%, no condensation
Earthquake resistance: host: 1.5m can withstand repeated fall (to the concrete floor)
Illumination rating: 0 to 75000lux
Dustproof: IP41
Electrical Parameters
Input voltage: 5VDC + 0.25V
Operating power: 700mW (140mA, 5VDC)
Standby power: 425mW (85mA, 5VDC)
Laser rating: Class1
Voyager 1250g decoding area:
Bar width scanning distance
Code39-5mil 57mm-139mm
Code39-7.5mil 28mm-245mm
Code39-10mil 9mm-369mm
Code39-13mil 0mm-446mm
