Xenon 1902 Color 2d scanner
Brand: Honeywell
Model: Xenon 1902 Color
Main features of the product:
1. ColorFusion panchromatic technology: to allow the scanning of color image collection and high contrast color bar code without reducing the performance of barcode scanning
2. Custom sensor which is most suitable for barcode scanning: improved scanning intensity and protected investment by increasing the stability of the supply chain
3. Two focal length choices: high density and standard spacing, which can provide scanning applications for specific USES, thus increasing production efficiency
4. Image processing software: providing advanced editing functions, such as cutting, lighting, rotation and sharpening, to make high-quality digital images
5. TotalFreedom ™ 2.0: secondary development platform, make on the scanner can be loaded and links to many applications, in order to enhance image processing, decoding, or data format processing functions, without modifications on the host
DetailParameterDownloadVideo data
Xenon 1902 Color technical parameters
Wireless communication performance
Radio frequency band / communication distance: 2.4 to 2.5GHz (ISM frequency band), adaptive frequency hopping (AFH), Bluetooth v2.1, Class 2, 10 meter visual distance communication
Data rate (transfer rate): 3Mbit/ seconds (2.1Mbit/ seconds)
Battery: minimum 1800 Ma lithium ion battery
Scanning times: each charge can be scanned nearly 50 thousand times
Expected operating time: 14 hours
Estimated charging time: 4.5 hours
Physical / electrical parameters
Scanner charger / communication base station
Dimensions (L * w * h) 104 mm x71 mm x160 mm 132 mm X102 mm x81 mm
Weight 214G 179g
Work power (charge) without 5W (1A@5V)
Non charge state power without 0.5W (0.1A@5V)
Host system interface without USB, keyboard port, RS232, IBW, 46XX (RS485)
Environment parameter
Operating temperature 0 degrees C to 50 degrees C charging: 5 degrees C to 40 degrees C
No charge: 0 degrees C to 50 degrees C
Storage humidity -40 degrees C to 70 degrees C, -40 degrees C to 70 degrees C
Humidity 0% to 95% relative humidity, no condensation, 0% to 95% relative humidity, no condensation
Anti fall strength can withstand 50 times 1.8m air fall, can withstand 50 1m air fall
Industrial grade IP41 IP41
Light rating 0 to 100000Lux (9290 feet of candle light) without
Scanning performance
Scan mode two-dimensional image (838 x, 640 pixel array)
Anti jitter best focus scanning 13mil UPC code can reach 610 cm / sec
Scanning angle high density H: level: 41.4 degrees; vertical: 32.2 degrees
Standard distance SR: level: 42.4 degrees: vertical: 33 degrees
Long distance ER: level: 31.6 degrees: vertical 24.4 degrees
A reflectance difference of 20% at the lowest reflex contrast is recognized
Slope, skewness 45 degrees, 65 degrees
Decoding capabilities can be soviet standard, one-dimensional, stacked, two-dimensional bar code and postal code, and specific OPCR fonts
