hardware
Dimensions are marked (W * D x H) 110 * 215 * 172
Machine type heat sensitive computer label printer
The weight of 1340 g
Interface MiniUSB (2.0); Rs-232c (optional serial port converter)
There is no keyboard
Shear hand
Power supply 100-240v 50Hz / 60Hz (maximum consumption power is not greater than 150W)
Printing height of 56mm
The width of the ribbon (mm) is the widest of 63mm
Heat sensitive to print
Printing precision 200dpi
Print speed 152.4 mm/SEC
Random attachment cd-rom/USB data line/power line/ac power adapter/use instruction (with warranty)
features
Text modification of computer fonts
Any size within the effective range of font size
Image printing has
Serial number printing (1-9999 / A ~ Z/A ~ Z)
Print lines are the size of the font
Border 126
Automatic format has
6 MB memory
Multiple prints (1-9999)
Print preview
Barcode 19
Printer control command Raster, ESC/P, p-touch Template;
Date function
On both ends of the blank
System environment
Operating system, Microsoft ® Windows ® XP/Windows ® Vista/Windows 7 8 Microsoft/Windows ® ® ® Windows Server ® 2008 R2/2012/2003/2008
memory
Windows ® XP: 128 MB, WindowsServer ® 2003:256 MB,
WindowsVista ® / WindowsServer ® 2008 / R2/2012:512 MB,
Windows ® 7/8 GB (32-bit) or 2 GB (64)
Disk 70MB or more
Monitor SVGA/high color or higher
Interface MiniUSB (2.0), rs-232c (optional serial port converter)
Other cd-rom drives
PC software
Edit software p-touch Editor 5.0
Operating system, Microsoft ® Windows ® XP/Windows ® Vista/Windows 7 8 Microsoft/Windows ® ® ® Windows Server ® 2008 R2/2012/2003/2008
The driver is td-2020n
