Print head resolution 300dots/inch (12dots/mm)
Print carbon strip/heat sensitive
Dot size (width x length) 0.084 x 0.084 mm (1mm = 11.8 dots)
Print speed 2 ~ 4inch/s
Maximum printing width: 81mm (3.18)
Maximum print length 1524mm (60 ")
Interface type USB interface + serial port + interface
The outer diameter of carbon belt is 67mm
The carbon belt is 300 meters long
Carbon belt axis 1 inch (25.4 mm)
The carbon band width is 30mm ~ 90mm
Carbon - coil winding form
Paper internal paper volume outer diameter 127mm (5 ") OD
Paper type continuous paper, gap paper, folding paper, perforated paper
Paper wrap in the form of paper coil type/printed surface
Paper width (label + bottom paper) 20mm (0.78 ") ~ 90mm (3.54 ")
Paper thickness (label + bottom paper) 0.06 mm (2.36 mil) ~ 0.254 mm (10 mil)
Paper scroll heart size 25.4 mm ~ 38mm (1 "~ 1.5")
Tag length: 10 ~ 1524mm (0.39 "~ 60") remarks: if you use
The length of the label is less than 25.4 mm (1 "), which is recommended to use the tooth hole line
Label paper on the gap to tear apart
Gap paper spacing height: 2 mm (0.09 ")
The physical properties of the property are 185 (W) x 179 (H) x 290 (D)
Weight 2.4 KG
Automatic switching power supply for power supply
Input: AC 100 ~ 240V
Output: DC 24 v 2 a
Environmental elements working environment temperature: 5 ~ 45 ℃, humidity: 10 ~ 80%
Storage temperature: - 10 ~ 50 ℃, humidity: 10 ~ 90% (condensation)
* the above parameters are subject to change without prior notice.
