Print type heat sensitive
Resolution 203 dpi
The width of the printing paper is 16 ~ 82 mm
Print speed 150mm/SEC, common 127mm/SEC
Interface type serial port + USB + network port
Memory DRAM: 2M, FLSH: 2M
The printing head temperature detects thermistor
Print head position to detect micro switch
Paper exists to detect photoelectric sensors
Barcode character CODE128 / EAN128 / ITF/CODE39 / CODE93 / EAN13 EAN13 + 2 /
EAN13 + 5 / EAN8 EAN8 + 2 / + 5 / CODABA EAN8 / POSTNET/UPCA + 2 /
UPCA + 5 / UPCE + 2 / UPC/UPC - E - E + 5 / UPCE + 2 / UPC - E + 5 / CPOST /
MSI/MSIC/PLESSEY/ITF14 / EAN14 / QRCODE
FONT: 0 to FONT 8
The subcharacter amplification/rotation transverse longitudinal can be magnified 1 ~ 10 times, rotating printing (0 ~ 90/270/360 degree)
Graphics monochrome PCX, BMP and other image files can be downloaded to FLASH, DRAM
Medium paper type heat sensitive roll paper, adhesive, heat sensitive label paper etc
The medium width is 16 ~ 82mm
The paper volume is 85mm, minimum 25mm
To tear off or peel off paper
Power input 24DC, 2.0 A
The physical weight is 1.65 kg
Appearance size 156 x 230 x 147 mm (wide x depth x height)
Environmental elements working environment temperature: 5 ~ 45 ℃, humidity: 10 ~ 80%
Storage temperature: - 10 ~ 50 ℃, humidity: 10 ~ 90% (condensation)
