print
Way of print
thermal
The resolution of the
203 dpi
Print width
Maximum 76 mm
The printing speed
2 ~ 5 inches per second
The interface type
The USB interface
memory
DRAM: 2M, FLSH: 2M
Print head temperature detection
thermistor
Print head location detection
Micro switch
Paper detection
Photoelectric sensor
The bar code characters
The barcode
CODE128 / EAN128 / ITF/CODE39 / CODE93 / EAN13 EAN13 + 2 /
EAN13 + 5 / EAN8 EAN8 + 2 / + 5 / CODABA EAN8 / POSTNET/UPCA + 2 /
UPCA + 5 / UPCE + 2 / UPC/UPC - E - E + 5 / UPCE + 2 / UPC - E + 5 / CPOST /
MSI/MSIC PLESSEY/ITF14 / EAN14
Character set
FONT size: 0 to FONT 8
Sub - to enlarge/rotate
The horizontal vertical can be magnified 1 ~ 10 times, rotating printing (0 ~ 90/270/360 degree)
graphics
Monochrome PCX, BMP and other image files can be downloaded to FLASH, DRAM
medium
The paper type
Heat sensitive web paper, adhesive, etc
Medium width
From 25 to 82 mm
Paper roll
Maximum 115mm, minimum 25mm
The way of paper
In the paper
The power supply
The input
100 ~ 240VDC, 2A 50/60hz
The output
2.5 A 24 VDC
Physical properties
The weight of the
About 1.2 kg
Appearance of size
227 x 152 x 143 mm (D * W * H)
Environmental elements
The work environment
Temperature: 5 ~ 45 ℃, humidity: 10 ~ 80%
Storage environment
Temperature: - 10 ~ 50 ℃, humidity: 10 ~ 90% (condensation)
