Printing mode heat transfer
Resolution 203 dpi (8 point/mm)
Maximum printing speed 6 ips (152.4mm/s)
Maximum print width 4.25 "(108 mm)
Maximum print length 236 "(6000 mm)
Memory 8 MB FLASH ROM, 16 MB SDRAM
Width of label volume: maximum 4.56 "(116 mm), minimum 0.39 '(10 mm)
Outer diameter: maximum 8 "(203.2 mm), inner diameter: minimum 1.5" (38mm)
The label thickness is 0.0024 "-0.012" (0.06-0.305 mm), including the base paper thickness
Outer diameter of carbon belt: maximum 3.3 "(84 mm), inner diameter: 1" (25.4 mm)
Maximum width: 4.65 '(118 mm), maximum length: 1968' (600 m), both inside and outside carbon
Paper detection mode (mobile)/lower reflector (movable)/penetration (movable)
The text is printed with five dot matrix fonts and 24 matrix Chinese soong, which supports the download of Truetype fonts
Bar Code printing Code 39, the Code 93, Code 128 / subset of A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2
5 add - on, EAN - 13/8/128, ucc-128, etc.
MaxiCode, PDF417, Datamatrix, QR Code and other 2d barcodes
Interface rs-232 serial port, 10/100m - bit Ethernet port, USB DEVICE 2.0 interface, USB HOST interface, Centronics parallel port (optional)
The power rating is 100 ~ 240 V, 50/60 Hz, 3.5 A
The weight of 15 KGS
The fuselage size is 286 mm x depth 448 mm x height 280 mm
Working environment temperature: 0 ℃ to 40 ℃ (32 ° F ~ + 104 ° F). Relative humidity: 5% - 85% unexposed
Storage temperature: - 40 ℃, 60 ℃ (40 ° F ~ + 140 ° F). Relative humidity: 5% - 85% unexposed
Optional accessory cutter, external label rewind, Centronics
* the model and parameters of the customized version shall be subject to the specific product sheet.
