Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Print speed 4 IPS (102mm/s)
Print width 108 mm (4.25 ")
Print length Min. 0.16 (4 mm); Max. 68 "(1727 mm)
The processor 32-bit RISC CPU
Memory 8MB Flash (4MB for user storage) / 16MB SDRAM
Sensor form reflector: mobile
Permeable sensor: medium fixed type (dual sensor)
Paper type: continuous paper, spacing label paper, black line marker paper or punch paper, and the label length can be automatically detected or manually controlled
Paper width: minimum 25.4 mm (1) ~ 118mm (4.64)
Paper thickness: minimum 0.06 mm (0.003) ~ maximum 0.25 mm (0.01 ") * *
Paper roll diameter: the maximum diameter of 127 mm (5)
Paper scrolls: 25.4 mm (1), 38.1 mm (1.5 "), 76.2 mm (3)
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 981 "(300 m)
Width: the minimum 30 mm (1.18) ~ the maximum 110 mm (4.33)
Maximum size: 68 mm (2.67)
Shaft core: 25.4 mm (1)
The program language, EZPL, GEPL, GZPL, can be automatically switched
Random software label typesetting software: GoLabel (for EZPL only)
Driver: MAC, Linux, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1
DLL: Win CE,.net, Andriod, Windows Mobile, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1
The built-in font Bitmap font 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90 °, 90 °, 180 ° rotatable, single characters, 90 °, 180 °, 270 ° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Vector Fonts the vera.ttf Fonts (Bold Italic/Underline). 0 ° and 90 °, 180 °, 270 ° rotatable
Download font Bitmap fonts: Bitmap fonts, downloadable print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 180 °, and 270 °
Asian fonts: Asia downloadable fonts, print direction rotating Angle is 90 °, 180 °, 270 °, and can be horizontal or vertical amplifier 8 times
Vector fonts: vector fonts, downloadable print direction rotating Angle is 90 °, 180 °, and 270 °
1 d barcode: bar Code 39, Code 93, 8/13 (add on 2 & 5) EAN, UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), 128, EAN RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code,
Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11, Code 49, Cadablock
2D bar code: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8, UTF16BE, UTF16LE
The graphics processing default supports monochrome PCX, BMP, and other diagram types can be supported by software control
Communication interface USB 2.0 connection port (b-type)
Control panel a three-colour LED indicator: green, orange, red
A set of multifunctional hardware control keys: FEED keys
Power supply 100-240v AC, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity operating humidity: 30% ~ 85%, non-coagulation
Storage humidity: 10% ~ 90%, not condensation
EMC, FCC Class A, CB, CCC, UL, and cUL
Body size: 11.2 (285 mm)
Height: 6.8 "(171 mm)
Width: 8.9 (226 mm)
The weight of the body weight is 2.72 kg (6 LBS), which does not contain other consumables or choose and buy outfit
The selection of the paper roll holder (the maximum paper diameter is 250 mm / 10).
External forward/backward reels
Please refer to the original purchasing unit for the purchasing items. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
In response to different consumables, the actual printing size and printing speed must be determined by the actual consumables.
