Print mode thermal type
Resolution 203 dpi (8 dots/mm)
Print speed 4 IPS (102 mm/s)
Print width 2.12 "(54 mm)
Print length min.4 mm (0.16 inch); Max. 1727 mm (68 inches)
Memory 4MB Flash (the user has a capacity of 2MB); 16 MB SDRAM
Sensor form reflective sensors: portable; Permeable sensor: medium type fixed type
Paper type: continuous paper, spacing label paper, black line marker paper or punch paper, and the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003-inch) ~ 0.2 mm (0.008-inch)
Outside diameter: 127 mm (5 ") diameter
Paper reel core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch)
The program language, EZPL, GEPL. Automatic switching
Random software label typesetting software: QLabel - IV/GoLabel (supporting EZPL only)
Driver: Windows 2000, XP, Vista, 7, 8, Windows Server 2003 & 2008
DLL: Windows 2000, XP and Vista
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap font print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download the font Bitmap fonts, downloadable print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector fonts (scalable the font), print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, the Code 93, 8/13 (add on 2 & 5) EAN, UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), 128, EAN RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255
Unicode (UTF8, UTF16)
The graphics processing preset supports monochrome PCX, BMP, and other diagram types can be supported by software control
Port of communication: rs-232 (DB - 9)
USB port
10/100 MBPS Ethernet print server
Control panel a three-color LED indicator: power (green, orange, red)
A set of multifunctional hardware control keys: feeds
The timing device is built in standard
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, cUL, CCC
Body size: 218 mm (8.58 ")
Height: 172 mm (6.77 ")
Width: 100 mm (3.94 ")
The body's weight is not contained in any other consuming materials or is equipped with an optional weight of 1.2 kg (2.65 pounds)
Select the knife of the purchase item
Automatic stripper
External paper holder (the maximum paper diameter is 10 inches)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
* * in response to different consumables, the actual printing size should be determined by the actual consumables.
