Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Print speed 7IPS (177 mm/SEC)
Print width 54 mm (2.12 inches)
Print length Min. 4 mm (0.16 inch) * *; Max. 1727 mm (68 inches)
Memory 8MB Flash (4MB of user space); 16 MB SDRAM
Sensor form reflective sensors: portable; Penetration sensor: medium fixed type
Paper type: continuous paper, spacing label paper, black line marker paper or punch paper, and the label length can be automatically detected or manually controlled
Paper width: 15 mm (0.6 inch) ~ 60 mm (2.36 ")
Paper thickness: 0.06 mm (0.003-inch) ~ 0.2 mm (0.008-inch)
Outside diameter: 127 mm (5 ") diameter
Paper reel core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch)
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 110 m (360 ft)
Width: 56 mm to 59 mm (2.20 inches to 2.32 inches)
Maximum size: 40mm (1.57 inches)
Shaft core: 12.7 mm (0.5 inch)
The program language, EZPL, GEPL. Automatic switching
Random software label typesetting software: GoLabel (for EZPL only)
Driver: supports Windows 2000, XP, Vista, Windows Server 2003 & 2008
DLL: supports Windows 2000, XP and Vista
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap font print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download the font Bitmap fonts, downloadable print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font can be single rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector fonts (scalable the font), print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, the Code 93, 8/13 (add on 2 & 5) EAN, UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), 128, EAN RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)
Graphics processing support monochrome PCX, BMP, and other diagram types can be supported by software control
Communication interface serial port: rs-232 (DB - 9)
USB 2.0
Ethernet 10/100 Mbps print server
External USB device
Control panel color LCD display screen and operating key
Function key: FEED the paper key
The power switch
Automatic paper detection key
Timing device standard configuration
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, CCC, cUL
Length of body: 245 mm (9.7-inch)
Height: 175 mm (6.9 inches)
Width: 136 mm (5.3 inches)
The body weighs two kilograms (4.4 pounds) without any other materials or options.
Purchase project USB + RS232 port module (project to be installed and optional)
The cutting
Peel paper
External paper holder (the maximum paper diameter is 10 inches)
External forward/backward reels
Please consult the original purchasing unit for the purchase item. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
* * in response to different consumables, the actual printing size should be determined by the actual consumables.
