Printing mode heat transfer/heat transfer
Resolution 300dpi (12 dots/mm)
Printing speeds up to 5 IPS (127 mm/s)
Print width 105.7 mm (4.16 inches)
Print length printing length is 4 mm (0.16 ") * *; the printing length is 762 mm (30).
The processor 32-bit RISC CPU
Memory 8MB Flash (user capacity is 4MB); 16 MB SDRAM
Sensor form reflective sensors: portable; Penetration sensor: medium fixed
Paper type: continuous paper, pitch paper, black line mark paper or punch paper, the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 ") ~ 118 mm (4.46 ")
Paper thickness: 0.06 mm (0.003-inch) ~ 0.2 mm (0.01 inch)
Outside diameter: 127 mm (5 ") diameter
Paper roll core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch)
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 300 m (981 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum size: 68 mm (2.67 inches)
Shaft core: 25.4 mm (1 inch)
The program language, EZPL, GEPL. Automatic switching
Random software label typesetting software: GoLabel (supporting EZPL only)
Driver: supports Windows 2000, XP, Vista, 7, and Windows Server 2003 & 2008
DLL: supports Windows 2000, XP and Vista
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download the font Bitmap fonts, downloadable print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font can be single rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector fonts (scalable font), the print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, 93, EAN Code (add 8/13 on 2 & 5), UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset of A, B, C), 128, 128, 128, UCC RPS EAN UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, as well as GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)
Graphics processing supports monochrome PCX, BMP, and other diagram file types can be supported by software control
Communication interface USB2.0 port
The rs-232 (db-9) serial port
10/100 MBPS network
Control panel two LED indicator lights: Ready, Status
A set of multifunctional hardware control keys: feeds
Power supply/key
Paper detection key
The timing device is built in standard
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, CCC, cUL
Body size: 280 mm (11 ")
Height: 186 mm (7.3 inches)
Width: 210 mm (8.3 inches)
The body's weight is not contained in any other consuming materials or is equipped with a weighing of 3 kg (6.6 LBS).
Select the knife of the purchase item
Bluetooth module
Peel paper
External paper holder (250mm / 10 diameter)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
The actual printing size and printing speed should be determined according to the actual consumables.
