Printing mode heat transfer/heat transfer
Resolution 600 dpi (24 points/mm)
Printing speed 3 IPS (76.2 mm/s)
Print width 105.6 mm (4.16 inches)
The length of the printed length is 4mm (0.16 inches).
The printing length is 381 millimeters (15 inches)
The processor 32-bit RISC CPU
Memory Flash: 128 MB Flash (the user can use 60 MB)
32 MB SDRAM:
Sensor form reflector: mobile
Permeable sensor: medium type fixed type
Paper type: continuous paper, spacing label paper, black line marker paper or punch paper, and the label length can be automatically detected or manually controlled
Paper width: 20mm (0.79 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003 inch) ~ 0.20mm (0.008 inch)
Outside diameter: 127mm (5in) diameter
Paper reel core: 25.4 mm (1 inch), 38.1 mm (1.5 inch)
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 110 meters (360 ')
Width: 30mm (1.18-inch) ~ 110mm (4.33in)
Maximum external diameter: 40mm (1.57in)
Shaft core: 12.7mm (0.5 inch)
The program language, EZPL, GEPL, GZPL, can be automatically switched
Random software label typesetting software: GoLabel (for EZPL only)
Drivers: MAC, Linux, Windows 2000, XP, Vista, Windows 7 8.1 and 10, Windows Server 2003 & amp; 2008
DLL: Win CE,.net, Windows Mobile, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1 / Android
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16x26, and OCR A& B
Print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 180 °, 270 °, and can be horizontal or vertical amplifier 8 times
Vector fonts: scalable fonts (bold italic/bottom line), rotating Angle is 90 °, 180 °, and 270 °
Download font Bitmap fonts: Bitmap fonts, downloadable print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 180 °, and 270 °
Asian fonts: Asia downloadable fonts, print direction rotating Angle is 90 °, 180 °, 270 °, and can be horizontal or vertical amplifier 8 times
Vector fonts: scalable fonts (bold italic/bottom line), rotating Angle is 90 °, 180 °, and 270 °
One-dimensional bar Code bar Code: the Code 39, Code 93, EAN - 8, EAN 13, EAN 8/13 (with 2 & amp; 5 who leads the extension), UPC - A, UPC - E, UPC -a and UPC - E with EAN 2 or 5 digit extension, Interleaved 2 - of - 5 (I 2 of 5), Interleaved 2 - o - f 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Postnet, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & amp; 13 digit, Japanese Postnet, Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11, ISBT -128, Code 32
2d bar code: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code, code 49, Codablock F, TLC 39
Codepage 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
Windows 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8, UTF16BE, UTF16LE
The graphics processing default supports monochrome PCX, BMP, and other diagram types can be supported by software control
Communication interface USB 2.0 port
USB Host
The rs-232 (db-9) list port
10/100mbps Ethernet print server
Coordinate port (factory installation)
Control panel 3.2 inch touch color LCD display
A set of multifunctional hardware control keys: feeds
Power supply/key
The paper detects key
The timing device is built in standard
Power supply 100-240v AC, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing
Storage humidity: 10-90%, non-condensing
(EMC), FCC Class A, CB, cUL, EAC, BIS, CCC
Body size: 280 mm (11.0 inch)
Height: 195 mm (7.7 inches)
Width: 210 millimeters (8.3 inches)
The body's weight is not contained in other materials or is equipped with a weight of 2.7 kg (5.9 LBS).
The selection of project shaper
The cutting
External paper holder (250mm / 10in diameter)
External forward/backward reels
Bluetooth module (distributor installation)
WiFi printing server (distributor installation)
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
* * * in response to different consumables, the actual printed size and printing speed must be determined by the actual consumables.
