Technical parameters:
The printer specifications
The resolution of the
203dpi (8dots/mm), 300dpi (12dot/mm) (optional), 600dpi (24dot/mm) (optional)
memory
Standard: 256 MB RAM, 512 MB Flash
Print width
4.09 inches / 104 mm
Print the length of the
203 dpi: 3988 mm; 300 dpi: 1854 mm; 600 dpi: 600 mm
The printing speed
14 inches per second (356 mm/SEC)
Dielectric sensors
Transmission and reflection
Medium parameters
Medium width (label and the bottom paper)
1 inch / 25.4 mm to 4.5 inches / 114 mm, tearing/paper cutting machine; 1 inch / 25.4 mm to 4.25 inches / 108 mm strip/roll back
The maximum length of discontinuous tag
39 inches / 991 mm
The largest volume size medium
8 inches / 203 mm, volume 3 inches/core diameter 76 mm core diameter
The thickness of the medium
0.0023 inch / 0.058 mm / 0.25 mm to 0.010 inches
Medium type
Continuous paper, die-cutting paper, notched paper, black label paper
Carbon with parameters
Carbon with maximum overall diameter
450 meters: 3.2 inch / 81.3 mm, volume 1 inch / 25.4 mm core diameter core diameter
The length of the standard
1476 '/ 450 meters
The width of the
51 mm to 4.33 inches 2.00 inches / / 110 mm
Carbon tape
Carbon with ink for winding; Choice of carbon belt scroll can be used for carbon ink for winding.
Working parameters
Working temperature
40 ° F / 5 ° C to 105 ° F / 41 ° C
Storage temperature
To 40 ° F/to 40 ° C to 140 ° F / 60 ° C
Working humidity
20-85%, without condensation
Store humidity
5-85%, without condensation
Physical specifications (closed)
The width of the
10.6 inches / 269 mm
highly
12.75 inches / 324 mm
The length of the
19.50 inches / 495 mm
The weight of the
36 pounds / 16.33 kg
The font/graphics/symbol
The font/character set
Seven kinds of bitmap fonts, 1 kind of smooth scalable fonts support OpenType fonts
Multilingual support - in line with the Unicode standard, can be directly for quick multilingual on-demand thermal printer.
Contains the Monotype Imaging Inc. UFST line
Graphical capabilities
Support for user-defined fonts and graphics including custom micrographics
ZPL ll drawing commands a apply to box and the lines
Bar code
One dimensional barcode: Code, Code 39, Code 93, 11 with A subset of the A/B/C Code 128 and UCC Case, UPC Codes, ISBT - 128 - A, UPC - E, EAN - 8, EAN - 13, UPC and EAN 2 - or five - digit extensions, Plessey, Postnet, Standard 2-2 - of - 5-5, Industrial, Interleaved 2 - of - 5, Logmars, MSI, Codabarand Planet Code
Two dimensional barcode
Codablock, PDF417, 49 Code, Data Matrix, MaxiCode, QR Code, TLC, 39, MicroPDF RSS - 14 (and emoticons), Aztec
