DetailParameterDownloadVideo data
• Intuitive printer setup, print quality, self-service wizard
• Large full-color display with easy-to-use navigation keys
• Easy access to side consumables for loading
Seamless integration with the industry's broadest print simulation library, including Postscript/PDF printing
• Quick replacement of memory cards (optional) to store printer configurations and network Settings for easy installation of new printer industrial performance
• High-speed printing CPU and extended memory for fast printing with shorter first print time
• Easily print 15,000 labels per day in demanding environments
• Rugged, all-metal cabinets designed to work 24/7 in the harshest environments, serving the most demanding global customers
• Includes PrintNet Enterprise's robust remote printer management software
• Verify output with compatible SOTI Connect device management solutions
• Integrated bar code validator that generates 100% scannable 1D and 2D barcodes at a time to avoid violation fines and refunds
• The fully integrated solution automatically retrieves, invalidates and reprints nonconforming labels
• Automatic capture of graded reports can be used for fine defense and regulatory audit scans up to 4 inches wide, compatible
•4 - and 6-inch printer models
T8000 | Specifications sheet
Model T8000 4 inches T8000 6 inches T8000 8 inches
The resolution is 203dpi or 300dpi
Print modes Thermal and thermal rotary
Maximum print speed 14ips@203dpi, 12ips@300dpi 12ips@203dpi, 10ips@300dpi 10ips@203dpi, 8ips@300dpi
Maximum print width 4.1 inches (104 mm) 6.6 inches (168 mm) 8.5 inches (216 mm)
Paper type Roll or fan folding labels, papers, films, bills
Paper delivery standard: continuous, multi-sheet tear, single tear/optional: stripping, cutting and backwinding
Paper width minimum 1 inch (25.4 mm) /
Max. 4.5 inches (114.3 mm)
Min. 2 inches (50.8 mm) /
Max. 6.8 inches (172.7 mm)
Min. 3 inches (76.2 mm) /
Max. 8.75 inches (222.2 mm)
Paper thickness from 0.0025 inches (0.00635 mm) to 0.010 inches (0.254 mm)
Minimum paper length: continuous, torn paper 0.25 inch (6.35 mm)
Minimum: Peel, cutter 1.0 inch (25.4 mm)
Max. : 99 inches (2,515 mm)
Reel core sizes 1.5 inches (38.1 mm) to 3.0 inches (76.2 mm)
Max paper reel diameter 8.0 inches (209 mm)
Carbon strip type wax, wax/resin, resin
Carbon strip width minimum 1 inch (25.4 mm) /
Max. 4.5 inches (114.3 mm)
Min. 2 inches (50.8 mm) /
Max. 6.8 inches (172.7 mm)
Min. 3 inches (76.2 mm) /
Max. 8.75 inches (222.2 mm)
Carbon strip length 2050.5 ft (625 m)
Carbon tape reel diameter 1.0 inch (25.4 mm)
Interface I/O standard: RS232 serial interface, USB interface and Ethernet 10/100Base T
Optional: Wi-Fi 802.11a/b/g/n/ac, GPIO, Parallel
WiFi Security Encryption WEP 40/128bit, WPA Personal (PSK), WPA2 Personal (PSK) Enterprise (AES CCMP)
WiFi security authentication EAP-TLS, EAP-TTLS, PEAPv0/MS-CHAPv2, PEAPv1, EAP-MDS, LEAP
Remote management software PrintNet Enterprise Edition suite
SOTI Connect: iot device management
Memory 128 MB Flash / 512 MB DDR
Input voltage automatically ADAPTS to 90-264 VAC (48-62 Hz)
Font Font technologies: Intellifont, TrueType, Unicode
Standard fonts: OCRA, OCRB, Courier, Letter Gothic, CG Times, CG Triumvirate/ bold/compressed
Asian font (optional SD card) : Simplified Chinese, Japanese, Korean
Andale Font (optional SD card) : Simplified Chinese, Traditional Chinese, Korean, Japanese
PDF/PostScript level 3:35 fonts
Graphics format PCX, TIFF, BMP, and PNG
Barcode One-dimensional barcode: BC-412, Code 11, Code 39, Code 35, Code 93, Codabar, Code128 Subsets A/B/C, Industrial 2 of 5, Interleave 2 of 5, Codabar, code128 Subsets A/B/C
German I-2/5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET,
4-state PostBar, Australian 4-state, FIM, ITF14, TELEPEN, PLANET, USPS Intelligent Mail, LOGMARS
2D barcode: PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR Codes, Aztec, GS1 Databar (RSS-14)
Instruction set IGP: PGL VGL/ZGL/TGL/IGL/STGL DGL/IEGL/built/EGL
Job control: PJL and PTX-SETUP
Options: IPDS, TN5250, Postscript (Level 1.3)/PDF (Level 1.7)
PXML printer status and real-time label information are integrated into third-party software
ODV-2D
verifier
A fully integrated bar code validator that scores and reports all 1D barcodes, 2D barcodes and any orthogonal orientation for each label
Rated according to ISO 15415, 15416 and 15426 standards
Full backup and reprint labels with unqualified barcodes
Job grading report
Working environment Operating Temperature: 23°F to 104°F (-5°C to 40°C) (limited to selected paper)
Working humidity: 20-85% non-condensing
Storage temperature: 23°F to 140°F (-5°C to 60°C)
Storage humidity: 5 to 85% non-condensing
Safety certification emissions: FCC, CE, CCC
Safety: cTUVus, CE, EAC, SABS, RCM, CCC, KC, S-MARK, NOM
Environmental protection: RoHS, WEEE, Energy Star 3.0
Volume dimensions (W x H x D) 11.7 inches (297.2 mm) x 13 inches (330.2 mm)
x 20.5 inches (520.7 mm)
13.4 inches (340.4 mm) x 13 inches (330.2 mm)
x 20.5 inches (520.7 mm)
15.4 inches (391.2 mm) x 13 inches (330.2 mm)
x 20.5 inches (520.7 mm)
Weight 37 lb (16.7 kg) 40 lb (18.1 kg) 43 lb (19.5 kg)
Options and accessories Wi-Fi 802.11a/b/g/n/ac
Parallel port
GPIO
TN5250
PDF/PostScript
IPDS
ODV-2D integrated bar code verifier
Batch rollback 4 inches / 6 inches / 8 inches
4 "/ 6" / 8 "for ripping
High strength heavy duty cutter 4 "/ 6" / 8"
Premium Asian font card
Premium Andale Font card
QCMC (SD Quick Replacement Memory Card)
