The performance parameters
The processor
High speed quad-core 64-bit processor, 1.3 GHz
The operating system
Android 5.1 (64-bit version)
storage
1 gb RAM 8 gb ROM
interface
Micro USB 2.0, support USB charging
Physical parameters
Size (length x width x height)
165 * 72.5 * 24 mm
The weight of the
288 grams (battery)
display
3.7 "WVGA (resolution 800 x 480) industrial-grade capacitive touch screen
The keyboard
33 key (including the left and right buttons) keyboard, with backlight function
instructions
Vibrators, speakers, and multicolored leds
The battery
3.7 V, 3700 mah
camera
8 megapixel autofocus, LED lights
GPS
GPS (A - GPS)
extension
Micro SD card extension (up to 32GB)
Power adapter
Output: DC 5V, 2.0 A input: AC 100 ~ 240V, 50 ~ 60Hz
Environmental parameters
Working temperature
- 20 ℃ ~ 60 ℃
Storage temperature
- 30 ℃ ~ 70 ℃
Relative humidity
5% ~ 95% (no condensation)
Electrostatic protection
Plus or minus 15 kV (air discharge), plus or minus 8 kV (direct discharge)
Drop height
Six surfaces with six surfaces not less than 1.5 metres (each of six surfaces)
Protection grade
IP65
Read mode
1 d Barcode
Code128, UCC/EAN - 128, AIM 128, EAN - 8, jan-8, EAN - 13, ISBN/ISSN, upc-e, upc-a, Interleave 2/5, itf-6, itf-14, Deutsche 14, Deutsche 12, COOP 25, Matrix 2/5, Industrial 2/5, Standard 25, Code 39, Codabar/NW7, Code 93, Code 93, Code 11, Plessey, Plessey, MSI/Plessey, GS1 Databar and other one-dimensional barcodes
Laser (greater than 4 mil) (optional)
The 2 d Barcode
CMOS (= 5 mil) (optional)
Universal 1D barcode and PDF - 417, QR Code, Data Matrix, hanshin Code, etc
Wireless communications
WLAN RADIO
IEEE 802.11a/b/g/n, 2.4ghz and 5GHz
WWAN RADIO
2 g
GSM/GPRS/EDGE (900, 1800 MHZ)
3 g
Unicom WCDMA (Band1 / Band8);
Telecommunications CDMA2000 1X/ev-do rev.a (BC0)
Mobile td-scdma (Band34 / Band39)
4G (unicom, telecom, mobile)
The td-scdma LTE (Band38 / Band39 / Band40 / Band41)
FDD - LTE (Band1 / Band3)
WPAN RADIO
Bluetooth 4.0 LE, backwards compatible
Optional accessories
Charging base, battery, power adapter, data line, hand strap, satchel, and quadruple charger
* specifications are subject to change without prior notice
