Motorola DS457 2d fixed bar code reader

Brand: ZEBRA/Motorola
Model: Motorola DS457
Main features of the product:
1. Fully capture data - one-dimensional, two-dimensional, DPM and PDF417 barcode, driver's license resolution, stationary image, video and OCR
Provide a variety of products, can meet any fixed - type to avoid scanning demand
2. Scan paper, mobile phone and any bar code displayed on the computer monitor
The bar code on all the media can be scanned. Support your customer's preferred technology-mobile barcode
Powerful 624 MHz processor, rapid sensor shutter, and rapid pulse lighting for patent applications
Capable of scanning all barcodes at an excellent rate; Improve throughput and productivity
4. Compact and streamlined design
Can be installed anywhere; It is suitable for the design of retail stores and other customer-facing areas
5. Installation accessories
It can be easily installed in the place of need - the cashier, the counter, etc
6. Omnidirectional scanning
You don't need to align the bar code and the scanner; More ergonomic, use more comfortable
7. Unique targeting mode
Bright central spots ensure rapid, accurate scanning, even in bright sunlight
8. Scan trigger
The scanning trigger can be scanned and scanned in projection mode

DetailParameterDownloadVideo data

Physical parameters

Size: 29.5 mm high x 58.4 mm long x 62 mm wide

Weight: 111 g

Power: maximum: 5VDC + / -10% @ 450mA

The performance parameters

Sensor resolution: 752 x 480 (horizontal) (vertical) gray-scale two-dimensional bar code reader horizon: DS457 - SR and DL: level of 39.6 ° and 25.7 ° vertically; DS457 - HD and DP: level of 38.4 ° and 24.9 ° vertically

Target component: 655 + + 10 nanometer (VLD)

Lighting components: 625 + 5 nm (LED)

Minimum print contrast: minimum 25% absolute black/light reflection ratio

Barcode decoding ability

One dimension: all major one-dimensional barcode

2d: PDF417, DataMatrix, QR code, Aztec, composite code, MaxiCode

Postal code: U.S.P ostnet, U.S.P lanet, UL Postal, Japan Postal

Using the environment

Ambient light immunity: all dark to 96900lux

Working temperature: - 20 ° C to 50 ° C

Storage temperature: - 40 ° C to 70 ° C

Humidity: relative humidity 5% to 95%, no condensation

Seal: IP54

Drop specification: can withstand the impact of several times from 76 cm height to concrete ground

Programming parameters: power mode, trigger mode, buzzer ring, session time, focus control, camera control, image control, advanced data format, document collection, and signature collection

Image file format: BMP, TIFF, JPG

interface

Support interface: 9 pin male d-sub - USB (full speed) and TTL level RS232, RTS and CTS

The warranty

Three years warranty

DS457 decoding region (typical)

The bar code density DS457 - SR/DS457 - DL scan the depth of field DS457 - HD/DS457 - DP

Code39-3mil is not tested 3-12.2cm

Code39-5mil 3.3-20.6cm 2.8-14.5cm

Code39-20mil 4.6-41.9 cm 4.8-24.6 cm

Upc-13mil 3.8-38.9 cm 4.3-21.1 cm

Datamatrix - 4mil failed to test 4.3-21.1 cm

Datamatrix - 5mil untested 3.6-9.4 cm

Datamatrix - 7.5 mil 5.1-15.2 cm 3.0-11.2 cm

Datamatrix - 10mil 3.8-21.3 cm untested

The datamatrix-15mil 4.1-27.7cm is untested

QR code -5mil is not tested 3.8 to 7.9 cm

QR code - 7.5 mil 5.3-13 cm 2.8-10.2 cm

QR code - 10mil 3.8-17.8 cm 2.8-11.7 cm

Pdf417-4mil was not tested for 3.6-9.7 cm

Pdf417-6.67 mil 4.6-18 cm 2.5-12.2 cm

Pdf417-10mil 3-25.9 cm untested

Pdf417-15mil 3.8-33cm untested
