Physical/environmental parameters
Volume: standard battery: 134mmL * 73mmW * 18mm; Large capacity battery: 134mmL * 73mmW * 23.9mm
Weight: standard battery: 204g, large capacity battery: 244g
Operating temperature: - 20 ℃ to 50 ℃
Storage temperature: 25 ℃ to 70 ℃
Relative humidity: 95 % relative humidity, no condensation
Resistance to fall: fall from 1.2m to cement at operating temperature
Anti-roll ability: standard battery configuration: according to the standard of iec60068-2-32, it can withstand the rolling of more than 1,000 times and 0.5 meters; Large capacity battery configuration: according to the standard of iec60068-2-32, it can withstand more than 300 times within 0.5m range
Environmental seal level: anti-moisture and particulate erosion can reach IP54 standard
Anti-static: + 8kV contact discharge; Plus or minus 15kV air discharge
System construction
Processor: 1GHZ mononuclear TI OMAP
Operating system: Microsoft Windows Embedded 6.5 or Google Andriod4.0 with honeywell security and management functions
Memory: 512MB RAM, 1GB FLASH
Display: 4.3-inch WVGA (480 * 800), super bright and visible in sunlight
Touch screen: dual touch capacitive screen, enhanced durability and better visibility of sunlight
Keyboard: dedicated scan, 4 programmable keys, volume lift keys, side scan keys, honeywell virtual keyboard and keyboard generator
Audio: microphone with speaker, echo and noise cancellation
I/O interface: micro USB interface, 3.5mm headset/microphone combination jack
Camera: 5 megapixel camera with auto-focus and flash function
Sensors: acceleration, vibration, ambient light and proximity sensor sensors
Storage extension: Micro SD card slot (compatible with SDHC)
Battery: standard: lithium battery, 3.7 V, 1670mAh; Large capacity: lithium battery, 3.7 V, 3340mAh
Length of operation: use standard to take you through 3G network call: 6 hours (reference); Using a large capacity battery to communicate via 3G network: 12 hours (reference)
Decoding ability: professional image engine, can interpret standard 1D and 2D bar code
Development environment: the honeywell SDK for Microsoft Windows Embedded Handheld6.5; Honeywell SDK for Google Android4.0
HSM application: honeywell Powertools and demos are used for RemoteMasterMind software for remote management of mobile devices
Warranty period: 1 year factory warranty
A wireless connection
WLAN: IEEE 802.11 a/b/g/n
WLAN safety standards: WEP, 802.1 x, WPA2, EAP, WEP, LEAP, TKIP, MD5, EAP - TLS, EAP - TTLS, wpa-psk, PEAP, CCXv4
WPAN: 2.4 GHz Bluetooth v2.1, support EDR2.0 Mbps and 3.0 Mbps Rates ClassII (10m)
WWAN: 3.9 G, HSPA + / UMTS (850/1900/2100MHz), GSM/GPRS/EDGE (850/900/1800/1900MHz) EVDO, a-gps
