Printing mode heat transfer
Resolution 300 dpi (11.8pm/mm)
Maximum printing speed 8 ips (203.2 mm/s)
Maximum print width 4.17 (106 mm)
Maximum print length 79 "(2000 mm)
Memory 8 MB FLASH ROM, 16 MB SDRAM
Label volume width: maximum 4.56 "(116 mm), minimum 0.98 '(25mm)
Outer diameter: maximum 8 "(203.2 mm), inner diameter: minimum 3" (76.2 mm)
The label thickness is 0.0024 "-0.012" (0.06-0.305 mm), including the base paper thickness
Outer diameter of carbon belt: maximum 3.3 "(84 mm), inner diameter: 1" (25.4 mm)
Maximum width: 4.65 '(118 mm), maximum length: 1968' (600 m), both inside and outside carbon
Paper detection mode (mobile)/lower reflector (movable)/penetration (movable)
Text printing PPLE instructions: built-in five dot matrix fonts and 24 matrix Chinese song body, support to download Truetype font
PPLZ directive: the built-in seven dot matrix fonts and a vector font support for downloading Truetype fonts
Bar Code printing Code 39, the Code 93, Code 128 / subset of A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2
5 add - on, EAN - 13/8/128, ucc-128, etc.
MaxiCode, PDF417, Datamatrix, QR Code and other 2d barcodes
Interface RS - 232 serial port, 10/100M - bit Ethernet port, USB DEVICE 2.0 interface, USB HOST interface, Centronics and interface
The power rating is 100 ~ 240 V, 50/60 Hz, 3.5 A
The weight of 15 KGS
The fuselage size is 286 mm x depth 448 mm x height 280 mm
Working environment temperature: 0 ℃ to 40 ℃ (32 ° F ~ + 104 ° F). Relative humidity: 5% - 85% unexposed
Storage temperature: - 40 ℃, 60 ℃ (40 ° F ~ + 140 ° F). Relative humidity: 5% - 85% unexposed
Optional accessory cutter, external label rewind
* the model and parameters of the customized version shall be subject to the specific product sheet.
