Printing mode heat transfer
Resolution 203dpi (8 dots/mm)
Maximum printing speed 6ips (153 mm/s)
Maximum print width 4.25 "(108 mm)
Maximum print length 315 (8000 mm)
Memory 8MB FLASH ROM, 16MB SDRAM
Width of label volume: maximum 4.49 "(114 mm), minimum 0.98 '(25 mm)
Outer diameter: maximum 6 "(152 mm), inner diameter: minimum 1" (25.4 mm)
The label thickness is 0.003 "-0.008" (0.08-0.20mm), including the bottom paper thickness
Carbon belt size: maximum 2.75 (70mm), inner diameter: 1 "(25.4 mm)
Maximum width: 4.33 '(110 mm), maximum length: 984' (300 m)
Paper detection mode reflector (movable)/penetration type
The text prints five dot matrix fonts and 24 matrix Chinese fonts, and supports downloading TrueType fonts
Bar Code printing Code 39, the Code 93, Code 128 / subset of A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2
5 add - on, EAN - 13/8/128, ucc-128, etc.
MaxiCode, PDF417, Datamatrix, QR Code and other 2d barcodes
Interface RS - 232 serial port, 10/100m - bit Ethernet port, USB DEVICE 2.0 interface,
USB HOST interface, Centronics (optional)
LCD display four lines of graphic dot matrix
Power adapter input: ac 100 ~ 240 V, 50/60 Hz output: dc 24 V, 4.0 A
Weight is 3.5 KGS
The fuselage size is 256 mm x depth 329 mm x height 200 mm
Working environment temperature: 0 ℃ to 40 ℃ (32 ° F ~ + 104 ° F). Relative humidity: 5% - 85% unexposed
Storage temperature: - 30 ℃, 60 ℃ (22 ° F ~ + 140 ° F). Relative humidity: 5% - 85% unexposed
Optional accessory cutting knife, Centronics parallel port, external paper rack, paper strip, external label rewind, guide paper cap (the narrowest guide paper width is 8mm)
* the model and parameters of the customized version shall be subject to the specific product sheet.
