Printing mode heat transfer
Resolution 203 dpi (8 point/mm)
Maximum printing speed 4 ips (101.6mm/s)
Maximum print width 4.25 "(108 mm)
Maximum printing length 157 "(4000 mm)
Memory 8 MB FLASH ROM, 16 MB SDRAM
Width of label volume: maximum 4.72 "(120 mm), minimum 0.98 '(25 mm)
Outer diameter: maximum 4 "(102 mm)
The label thickness is 0.003 "-0.006" (0.08 -0.15 mm), including the base thickness
Diameter of carbon belt: maximum 1.5 "(38 mm), inner diameter: 0.5" (12.7 mm)
Maximum width: 4.33 '(110 mm), maximum length: 360' (110 m)
Paper detection mode reflectance (multiple installation locations)
The word print includes five kinds of dot matrix font and 24 dot Chinese song body, which supports downloading TrueType font
Bar Code printing Code 39, the Code 93, Code 128 / subset of A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2
5 add - on, EAN - 13/8/128, ucc-128, etc.
MaxiCode, PDF417, Datamatrix, QR Code and other 2d barcodes
Interface RS - 232 serial port, USB DEVICE 2.0 interface
Power adapter input: ac 100 ~ 240 V, 50/60 Hz output: dc 24 V, 2.5 A
Weight is 2.1 KGS
Body size 210 mm x depth 255 mm x high 150 mm
Working environment temperature: 0 ℃ to 40 ℃ (32 ° F ~ + 104 ° F). Relative humidity: 5% - 85% unexposed
Storage temperature: - 40 ℃, 60 ℃ (40 ° F ~ + 140 ° F). Relative humidity: 5% - 85% unexposed
Optional accessory cutting tool, external label rewind, guide slip cap (narrowest guide width 8mm)
* the model and parameters of the customized version shall be subject to the specific product sheet.
