Printing mode heat transfer/heat transfer
Resolution 300 dpi (12 dots/mm)
Printing speed 5IPS (127 mm/s)
Print width 104 mm (4.09 inch)
Print length min.4 mm (0.16 inch); 1143 mm (45 inches)
Memory 8MB Flash (user capacity is 4MB); 16 MB SDRAM
Sensor form reflective sensors: portable left aligned; Penetration sensor: portable left aligned
Material type: continuous paper, spacing label paper, black line mark paper or punch paper, the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003 inch) ~ 0.25 mm (0.01 inch)
Paper volume outside diameter: when using 76.2 mm (3 inch), the maximum diameter is 203.2mm (8 ") / 31mm (1.5inch), and the maximum diameter is 152.4 mm (6 ").
Paper roll core: 38.1 mm (1.5 ") ~ 76.2 mm (3 ")
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 450 m (1,471 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum external diameter: 76 mm (2.99 ")
Shaft core: 25.4 mm (1 inch)
The program language, EZPL, GEPL. Automatic switching
Random software label typesetting software: GoLabel (supporting EZPL only)
Driver & DLL: supports Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download font Bitmap fonts downloadable: 6, 8, 10, 12, 14, 18, 24, 30, 16 x26 and OCR A & B, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector (the vera.ttf font), print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, 93, EAN Code (add 8/13 on 2 & 5), UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars,
Codabar, Code 128 (subset of A, B, C), 128, 128, 128, UCC RPS EAN UCC/EAN - 128 - K Mart, the Random Weight,
Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, and GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)
Graphics processing supports monochrome PCX, BMP, and other diagram file types can be supported by software control
Communication interface USB2.0 port
RS - 232 serial port (DB - 9)
10/100 MBPS network
USB Host
Control panel three monochrome LED indicator lights: Power on, Ribbon out, and Media out
Three sets of multifunctional hardware control keys: feeds, PAUSE, and CANCEL
Paper detects the correct key
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
The timing device is built in standard
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, cUL, CCC
Body size: 512 mm (20.15 ")
Height: 291 mm (11.45in)
Width: 274 mm (10.78 inch)
The body weighs 15 kg (33 pounds) with no other materials or options.
Select the knife of the purchase item
Automatic stripping and backpaper recyclers
Parallel port (IEEE1284)
Automatic pasting machine interface connections (1 input, 3 outputs, power 500mA @5v, for project base)
External paper holder (250 mm / 10 inch diameter)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
The actual printing size and printing speed should be determined according to the actual consumables.
